Champion 100233 - (2) 3100 Watt Inverter Generator w/ Parallel Cable Kit (CARB)
Model:
EGD-100233-KIT
+
Share This Product
Recommended Accessories

Expert Recommended Accessories
Selected by Jared, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Recreational
Style
Portable
Run Watts
3,100 Rated Watts
Surge Watts
3,400
Starting Watts
Fuel
Gasoline
Engine
Champion

Champion 100233 - (2) 3100 Watt Inverter Generator w/ Parallel Cable Kit (CARB)
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- Champion RV-Ready Inverter Technology
- Clean, quiet power for campsites, RV's, cabins & tailgating
- 3400 Max Rated Starting Watts
- Powerful enough to start "Most" 13,500 BTU air conditioners
- True Sine Wave Output - Less Than 5% THD
- Safer power for your electronics and appliances
- Champion 192cc OHV Engine w/ Low Oil Shut-Off
- Provides added protection to extend the life of the generator
- Cast iron sleeve for long life and easy maintenance
- Economy Mode - Up to 7.5 Hours of Run Time @ 1/4 Load
- Adjusts engine speed to the optimum level depending on load
- Reduces fuel use and engine wear for extended operation
- TT-30 RV Receptacle
- Easily connect your 30A RV cord (Not Included) for quiet power
- Quiet - Only 59 dBA at 7M
- Fully enclosed durable housing reduces sound output
- Parallel Operation Capability (Includes Parallel Kit)
- Increase available wattage when linking (2) Champion 2800-3500W Inverters
- Lightweight Design w/ Built-In Carrying Handle
- Makes this generator easy to move where you need it most
- Integrated Wheels & Stow Away Handle
- Compact design for easy storage
- 12V DC Outlet
- Includes dual-port USB adapter charging phones, tablets, etc.
- Engine Oil NOT Included
- 3-Year Limited Warranty - EPA & CARB/50 State Certified
- (2) Champion 100233 - 3100 Watt Inverter Generator w/ RV Outlet (CARB) (100233)
- (1) Champion 100319 - Parallel Cable Kit For Champion Inverter Generators 2800W & Larger (100319)
Product Includes
California residents see
Warning: This product can expose you to chemicals including Benzene which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types





Product Includes
- (2) Champion 100233 - 3100 Watt Inverter Generator w/ RV Outlet (CARB) (100233)
- (1) Champion 100319 - Parallel Cable Kit For Champion Inverter Generators 2800W & Larger (100319)
EGD-100233-KIT

Overview
Weight
92.8 Pounds
Made in USA
No
Consumer Warranty
3 Years
Product Style
Portable Generator
Product Length
22.4 Inches
Product Width
17.3 Inches
Product Height
18.3 Inches
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Inverter
Auto Voltage Regulation
Yes
Rated Watts
3100 Watts
Combined Kit Watts
6000 Watts
Surge Watts
3400 Watts
Fuel Type
Gasoline
Rated Amps
26 Amps
Portability Kit
Never Flat Wheels
Tank Size
1.6 Gallons
Fuel Tank Material
Metal
Fuel Gauge
No
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
59 dbA
Idle Control
Yes
Hour Meter
No
Voltage Meter
No
Grade Type
Recreational
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
192 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Plugs
12-Amp DC - Cigarette Adapter
1
NEMA 5-20R - Wall-Type
1
RV Ready 30-Amp
1
USB
2
100233
Overview
Weight
92.8 Pounds
Made in USA
No
Consumer Warranty
3 Years
Product Style
Portable Generator
Product Length
22.4 Inches
Product Width
17.3 Inches
Product Height
18.3 Inches
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Inverter
Auto Voltage Regulation
Yes
Rated Watts
3100 Watts
Surge Watts
3400 Watts
Fuel Type
Gasoline
Rated Amps
26 Amps
Portability Kit
Never Flat Wheels
Tank Size
1.6 Gallons
Fuel Tank Material
Metal
Fuel Gauge
No
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
59 dbA
Idle Control
Yes
Hour Meter
No
Voltage Meter
No
Lifting Eye
No
Grade Type
Recreational
Engine
Engine Brand
Champion
Starting System
Recoil Start
CC
192 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Plugs
12-Amp DC - Cigarette Adapter
1
NEMA 5-20R - Wall-Type
1
RV Ready 30-Amp
1
USB
2
100319
General Information
Product Category
Generator Accessories
Overview
Product Category
Generator Accessories
Consumer Warranty
2 Years
Plugs
NEMA L5-30R
1
NEMA 14-50R
1
