Chicago Pneumatic 10-HP 30-Gallon Truck Mount Air Compressor w/ Briggs & Stratton Vanguard Engine
Model:
RCP-1030G
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Contractor
Style
Truck Mount
Engine Brand
Briggs & Stratton
CFM
14.35
Tank Size
30
- Gas Driven Compressor Delivers Great Performance And Value
- Handles the toughest service demands with ease
- Precision Engineering In A Rugged Package
- Solid Cast Iron Cylinder
- Fully Enclosed Belt Guard
- Cold Start Valve and pull type tank drain
- ASME/CRN certified tank and safety valves
- Convenient Professional Features
- 12 volt electric and recoil start
- (Battery not included)
- Engine slowdown (pilot valve)
- Oil monitor
- 2 year factory warranty, including valves
- Dependable 10 HP Briggs & Stratton Intek Engine
- Includes start key / panel to protect your investment
- Engine color may vary
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
RCP-1030G
Engine
HP
10
Engine Brand
Briggs & Stratton
Starting System
12-Volt Key Start w/ Recoil
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
14.35
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
30 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Horizontal
Overview
Weight
328 Pounds
Certification
ASME/CRN
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
45 Inches
Product Width
19 Inches
Product Height
38 Inches
Power Type
Gas
UPC
94922248954
