Cummins Onan RV QD12500 - 12.5HDKCB-11506G - 12.5kW RV Generator (Diesel)
Model:
A055E844
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Jared, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Recreational
Style
RV
Run Watts
12,500 Rated Watts
Voltage
120/240 Single-Phase
Fuel
Diesel
Engine
Cummins Onan
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- 12.5 kW Diesel Powered RV Generator (Model 11506)
- Designed for Type A RVs w/ 3 AC units (50A 2-Pole Breaker)
- Runs 3 15,000 BTU AC units w/ 5000 additional watts available
- Cummins Onan 1499cc Liquid-Cooled Diesel Engine
- Automatic timed glow plugs for quick & easy starting
- Elec. fuel pump w/ full oil & fuel filter (.48 Gal/h @ 1/2 Load)
- Microprocessor Controlled
- Self-diagnostic capability to simplify troubleshooting
- High Quality, Pure Sine Wave Electrical Output
- Digital voltage regulator prevents damaging spikes
- Computer-Controlled Variable Speed Operation
- Matches engine speed to load demand, minimizes noise levels
- Sound-Attenuating Design w/ USDA Approved Spark-Arrestor Muffler
- Lowers noise levels while providing cross-flow cooling
- Three-Point, Fully Focalized Mounting System
- Reduces vibration for quieter operation
- Stationary exhaust pipe connection point for easy installation
- Integrated Generator Set & Engine Control
- Provides user friendly controls and safety features
- 3 Year / 2000 Hour Warranty (Please See Warranty Sheet)
For Additional Models - Please Call Us @ 1-800-800-3317
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
A055E844
General Information
Product Category
Generator - RV
Overview
Product Category
Generator - RV
Weight
787 Pounds
Consumer Warranty
3 Years
Product Style
RV Generator
Product Length
41.4 Inches
Product Width
24.5 Inches
Product Height
27 Inches
UPC
765053289726
Additional Model Numbers
RV QD 12500, A055E844
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
12500 Watts
Fuel Type
Diesel
Rated Amps
52 Amps
Diesel Fuel Consumption @ 50% Load
.71 gallons/hr
Decibel Rating @ 3m
70
Idle Control
Yes
Hour Meter
Yes
Fuel Consumption
.38-1.28 gallons/hr
Circuit Breaker Size
50 Amps
Min. Air Inlet - Front
19" x 12"
Min. Air Outlet - Bottom
15" x 16"
Grade Type
Recreational
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
HP
27 HP
CC
1499 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
