Cummins Onan RV QG 3600 LP - 3.6KYFA-26120 - 3.6kW RV Generator (LP)

Model:

A055E865

Write A Review
$4,759.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Friday, Nov 22nd
Shipping to60601
synchrony card logo
$84 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Cummins Onan RV QG 3600 LP - 3.6KYFA-26120 - 3.6kW RV Generator (LP)
Cummins Onan RV QG 3600 LP - 3.6KYFA-26120 - 3.6kW RV Generator (LP)
Model: A055E865
$4,759.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Recreational

Style

RV

Run Watts

3,600 Rated Watts

Voltage

120 Single-Phase

Fuel

LP

Engine

Cummins Onan



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
    For Additional Models - Please Call Us @ 1-800-800-3317
  • 3.6 kW LP Powered RV Generator
  • Enough power to run one 15,000 BTU AC (30A 1-Pole Breaker)
  • Designed For Use With Multiple Applications
  • Fifth wheels, travel and sport utility trailers
  • Cummins Onan 4-Cycle OHV Engine (.6 Gal/H @ 1/2 Load)
  • Provides quiet operation w/ excellent fuel efficiency
  • Microprocessor Controlled
  • Digital voltage regulator prevents damaging voltage spikes
  • Provides added protection from overloads and faults
  • Sound-Attenuating Enclosure
  • Lowers noise levels while providing cross-flow cooling
  • Control Panel w/ LED Status Indicator Light
  • Start-Stop/Prime rocker switch
  • Provides set diagnostics
  • USDA Forest Service Approved Spark Arrestor Muffler
  • Enclosed design, reduces noise levels
  • Magnetic circuit breaker & fused DC circuits (to protect wiring)
  • 125" generator set output leads
  • Decibel Rating @ 3m: 68 db(A)
  • Cummins Spec Model 4KYFA26100
  • 3-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

A055E865
specs product image PID-6213
General Information
Product Category
Generator - RV
Overview
Product Category
Generator - RV
Weight
172 Pounds
Consumer Warranty
3 Years
Product Style
RV Generator
Product Length
30 Inches
Product Width
19.7 Inches
Product Height
14.4 Inches
UPC
690781001206
Additional Model Numbers

RV QG 3600, A055E865

Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
3600 Watts
Fuel Type
LP
LP Fuel Consumption @ 50% Load
0.6 gallons/hr
LP Fuel Consumption @ 100% Load
0.7 gallons/hr
Rated Amps
30 Amps
Decibel Rating @ 3m
68
Idle Control
No
Circuit Breaker Size
30 Amps
Min. Air Inlet - Front
7.2" x 5.1"
Min. Air Outlet - Bottom
9.6" x 3.8"
Grade Type
Recreational
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
CC
304 CC
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
