Cummins RS60 Quiet Connect™ Series 60kW Standby Power Generator (120/208V 3-Phase)
Model:
A054F821
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Jared, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
60,000 Rated Watts
Voltage
120/208 Three-Phase
Fuel
LP/Natural Gas
Engine
Cummins Onan
- Cummins Quiet Connect
- For light commercial applications w/ 120/208V 3-Phase power
- Powerd By Cummins 2.4L Turbocharged Liquid-Cooled Engine
- 1800 RPM design provides reliability and fuel efficiency
- Brushless CA Series Alternator
- Provides +/- 1% voltage & +/- 0.25% frequency regulation
- As close to utility power as you can get in a standby generator
- Advanced Design Sound Attenuated Aluminum Enclosure
- Aesthetically appealing withstands winds up to 180 MPH
- One of the quietest generators of its kind (69.8dB @ 7M)
- PowerCommand® Electronic Control
- Provides industry-leading self-diagnostic capabilities
- Flexible Exercise Mode
- Exercise at a time, frequency and duration that suits you
- Reducing unnecessary fuel consumption, emissions and noise
- Coolant Heater For Extreme Environmental Conditions (Included)
- Factory installed, Allows for cold weather starts down to -40 °F
- Automatic Transfer Switch (Sold Separately)
^Please Note - Requires Loading Dock or Forklift For Delivery^
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
A054F821
General Information
Product Category
Generator - Standby
Overview
Product Category
Generator - Standby
Weight
2634 Pounds
CARB Compliant
Yes
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
118.7 Inches
Product Width
40.0 Inches
Product Height
58.3 Inches
Additional Model Numbers
RS60-208, A054F821
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Rated Watts
60000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
60000 Watts
LP Power Capacity
60000 Watts
NG Fuel Consumption @ 50% Load
545.0 ft³/hr
NG Fuel Consumption @ 100% Load
933.8 ft³/hr
LP Fuel Consumption @ 50% Load
5.96 gallons/hr
LP Fuel Consumption @ 100% Load
10.17 gallons/hr
Rated Amps
208 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69.8 dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (540 CCA)
Enclosure
Aluminum
Circuit Breaker Size
250 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Cummins Onan
Starting System
12v Auto Start
CC
2400 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
