EMAX Industrial Silent Air 5-HP 60-Gallon Single-Stage Air Compressor (230V 1-Phase)
Model:
ESS05V060V1
+
Share This Product
Recommended Accessories

Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
8
Model: 21999-0177
$109.80
In-Stock
$86.00
In-Stock
Model: EATSPGPS1P
$61.26
Factory-Direct
Model: DXCM024-0400
$209.00
Factory-Direct
Model: F28070
$472.49
Factory-Direct
Model: 21999-0253
$752.40
Only 5 In-Stock
Model: EFKIT008AWB
Frequency
Frequency
Select how often you will receive your air filters, we offer many options to meet your air quality standards.
Quantity
Quantity
This will be how many filters you receive per delivery.
Quantity
Features
Grade
Contractor
Style
Single Stage 1-Phase
CFM
19
Tank Size
60
- Patented Silent Air Technology
- Piston intake noise is trapped and dissipated
- Provides 5-layer filtration ideal for heavy airborne particle work environments
- Reduces dBA Readings By Up To 35%
- Less than a household vacuum cleaner
- Ideal for applications where workers are close to the compressor
- Solid Cast Iron Pump
- Reliable construction; Rated up to 50,000 hours
- Removable disc industrial valves and 2 solid steel rods
- 5 HP 230 Volt 1-Phase Industrial Grade Motor
- 1750 RPM runs quieter and cooler; last longer
- Open drip-proof prevents liquid and solids from entering
- 60 Gallon Air Tank
- ASME rated for safety; 3/4" air outlet
- Includes isolation pads to lessen vibration and noise
- 16-Gauge Steel Belt Guard
- Durable enclosed prevents accidental injuries
- 1 Year Standard, 5 Year Extended, Extended Limited Lifetime Pump Warranty
- Please See Warranty Sheet For More Information
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
ESS05V060V1

General Information
Product Category
Air Compressor - Stationary
Engine
HP
5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
24
Recommended Breaker
40 Amp Breaker
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
19
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
150 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Product Category
Air Compressor - Stationary
Weight
550 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31 Inches
Product Width
24.5 Inches
Product Height
70 Inches
Power Type
Electric
UPC
810070052256
Reviews
(1)
EMAX ESS05V060V1 Reviews & Ratings

US Air Compressor With Decent Value
By Taylor J.
Utah
Purchased 10/28/2024 |
Review Posted 12/03/2024
The silent air system does help marginally with noise levels.
The air compressor is very efficient and puts off very little heat and water. And the CFM is as advertised. The quality is a 9.5 out of 10 due to some weld splatter that was not removed from the tank prior to paint and one of the fittings going to the tank from the pressure switch being loose.
Other than that it seems to be of good quality overall with a good warranty.
The air compressor is very efficient and puts off very little heat and water. And the CFM is as advertised. The quality is a 9.5 out of 10 due to some weld splatter that was not removed from the tank prior to paint and one of the fittings going to the tank from the pressure switch being loose.
Other than that it seems to be of good quality overall with a good warranty.
Taylor J. Recommends This
Was this review helpful?
Manufacturer Response
Thank your for your review and your feedback. We are sorry to hear about the quality issues. Unfortunately, with anything that is manufactured by humans hands there is always a possibility for errors to occur. We are working hard daily to improve our quality control to make sure our customers receive the best product. Feel free to contact us at 937-540-1141 with any technical support questions and/or concerns. Welcome to the EMAX Family!

Rating Breakdown
4/5
4/5
5/5
4/5
Pros:
Easy To Use, Reliable, Durable
Cons:
Expensive
