Franklin Electric SubDrive SolarPak - 7 GPM 3 HP Deep Well Submersible Pump
Model:
7SDSP-3.0HP
+
Share This Product
Features
Inlet Size
N/A
Style
Deep Well
GPM
7 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- 7 GPM 3 HP SubDrive SolarPak Solar Pumping System
- Rugged design for the challenges of remote & harsh environments
- Franklin Electric 4" Submersible 3 HP Motor & 7 GPM Pump
- Proven motor and pump technology for long-term reliability
- 3 HP / 2.2kW N3 SD Solar Controller w/ IP55, NEMA 3 Outdoor Enclosure
- 14/16 Ga. Robust, zinc-plated & powder coated steel w/ sliding door
- LED Display & Built-In RS-485 Data Port For Remote Telemetry
- Easy to read, push-button controls for easy programming/troubleshooting
- DC & AC Power Supply Input For Easy System Integration
- Auto switching to AC (Gen.) backup power if no DC (Solar) is available
- Built-In Diagnostics & Protection w/ (2) Controller Contacts (Level/Pressure)
- TRIP contact to detect dry-run conditions & prevent motor damage
- MPPT - Max Power Point Tracking & Motor Soft Start Feature
- Maximizes efficiency of input power & prevents water hammer
- Flow Switch w/ 30' Cable To Detect Low Flow or No Flow Conditions
- Prevents damage to the pump, motor, and plumbing
- Requires New Solar Array or Retrofit To Existing Solar Array
- DC Input Voltage:190V - 330V, Max Amps 12A DC, 2000-3500 Watts
- *See Manual/Spec Sheet For Sizing Req & Tech Info
- 1-Year Limited Warranty
Specifications
7SDSP-3.0HP
Motor
Voltage
240 Volt Single-Phase
Pump
Gallons Per Minute
7 Gallons
Outlet Diameter
1-1/4 Inch
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
483
Total Head Lift
1115 Feet
Submersible
Yes
Engine
Horsepower
3 HP
Overview
Assembly Required
Yes
Weight
100 Pounds
Consumer Warranty
1 Year
