Features
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- GenReady™ Advanced Outdoor Load Center
- Makes a home ready for a home standby generator
- Ideal during new construction or major electrical retrofit
- Hybrid Panel
- Operates as a normal load center
- Provides seamless integration of standby generators via EZ Switch
- EZ Transfer Switch Factory Installed
- Allows for manual or automatic opeartion of standby generator
- 200-Amp Main Load Center
- Dimensions are the same as a standard main load center
- 125A Circuit Breaker & 125A Lower Panel Circuit Switch
- NEMA 3R Enclosure
- Allows this panel to be installed outdoors or indoors
- Compatibility
- Designed for Guardian air-cooled and liquid-cooled generators
- Will NOT work with other standby generator brands
- Single panels are compatible with generators up to 125A/30 kW
- Single generators can support multiple GenReady load centers
California residents see
Warning: This product can expose you to chemicals including Di-n-butyl phthalate (DBP) which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
5454
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
50 Pounds
Made in USA
Yes
Consumer Warranty
1 Year
Product Length
42 Inches
Product Width
14.875 Inches
Product Height
5 Inches
UPC
696471054545
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
30000 Watts
Rated Amps
200 Amps
Enclosure
NEMA 3R
Max Utility Input
200 Amps
Max Generator Input
125 Amps
Maximum Wattage
30000 Watts
UL Listed
Yes
Reviews
(1)
Generac 5454 Reviews & Ratings
Product Q&A
(1)
Product Questions
Answered by Jared, the Generator Expert
Josh, if I have already ordered an automatic transfer switch do I also need this outdoor load panel?
John
from West Virginia
October 08, 2013
How-To Articles
How to Pick the Perfect Manual Transfer Switch
During a sudden power outage, you probably don’t feel like running multip...
How to Avoid Tripping a Generator With a Bonded Neutral
Does your generator outlet trip every time you connect it to your home's transf...
How to Pick the Perfect Power Transfer System
Power transfer systems are the easiest, most convenient way to restore power to...
Manuals
5454
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Generac GenReady™ Advanced Outdoor Load Center
