Generac MLT4060KVLED-STD - 6kW Towable Diesel Vertical Mast Light Tower w/ Kubota Engine & Electric Winch
Model:
MLT4060KVLED-STD4
+
Share This Product
Features
Grade
Professional
Style
Tow-Behind
Run Watts
6,000 Rated Watts
Voltage
120/240 Single-Phase
Fuel
Diesel
Engine
Kubota
- MLT4060KVLED-STD - 6kW Vertical Mast Light Tower (Kubota® / Electric Winch)
- Designed & engineered for optimum performance, reliability and longevity
- 4 × 320 Watt Generac G4 LED Luminaries
- Provides light coverage for up to 7 acres; Individual On/Off switches
- For maximum power and lower total cost of ownership
- Diffused design for highway applications requiring glare-free lighting
- 23-Foot, 5-Section Vertical Mast w/ Electric Winch
- Allows for quick setup, Raises mast in 15 seconds
- Vertical mast allows for more compact storage and transportation
- 359° Ground-Level Mast/Fixture Rotation w/ Locking System
- Distinctive angle fixture mount for common light distribution
- 1.0L Kubota® D1005 Liquid Cooled Diesel Engine (EPA Tier 4 Final)
- Fuel efficient design runs at 1800 RPM for extended engine life
- 56-Gallon Polyethylene Internal Fuel Tank
- Provides up to 187 hours of run time with all 4-light On
- 3.5" Fill port for easier access
- 120/240V - 50/25A Marathon Electric Brushless Alternator
- Robust design provides up to 6 kW of standby output
- (1) 120V 20A GFCI Duplex Outlet & (1) 240V 30A (L6-30R) Twistlock Outlet
- Individually breakered for added safety during operation
- 14-Gauge Steel Enclosure - 68 dB(A) @ 23'
- Powder-coated, UV and fade resistant paint for exterior/interior of enclosure
- Multi-lingual operating/safety decals; Manual holder w/ operating manual
- Tubular Steel Trailer w/ 48" Removable Tongue
- (4) 2000 lb. Adjustable leveling jacks; Transport/lock in horizontal storage position
- Front step platform for easy adjustment of light fixtures
- DOT Approved Tail, Side, Brake and Directional Lights
- 2200 lb. Leaf spring axle; Single wall polyethylene fenders
- 13" ST175/80D13 - 6 ply wheel/tire; 56" Axle Span
- 2" Ball hitch & safety chains w/ spring loaded safety hooks
- Includes Starting Battery
- CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
- 2-Year / 2,000 Hour Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon monoxide which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
MLT4060KVLED-STD4
General Information
Product Category
Light Tower
Overview
Product Category
Light Tower
Weight
1779 Pounds
Certification
EPA Tier 4
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Light Tower
Product Length
115 Inches
Product Width
68 Inches
Product Height
107 Inches
Additional Model Numbers
MLT4060KV-STD, MLT4060KVLED-STD4
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
6000 Watts
Fuel Type
Diesel
Rated Amps
50/25 Amps
Tank Size
56 Gallons
Fuel Tank Material
Plastic
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
68
Idle Control
No
Hour Meter
Yes
Lifting Eye
Yes
Battery
Included
Grade Type
Professional
Engine
Engine Brand
Kubota
Starting System
12-Volt Button Start
HP
13.1 HP
CC
1000 CC
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Plugs
NEMA 5-20R - GFCI
1
NEMA L6-30R
1
