Grundfos 5SQ07-320 - 5 GPM 3/4 HP SQ-Series Deep Well Submersible Pump (320' Rated Head) (2W - 200-240V)

Model:

96160135

Write A Review
Grundfos 5SQ07-320 - 5 GPM 3/4 HP SQ-Series Deep Well Submersible Pump (320' Rated Head) (2W - 200-240V)
Grundfos 5SQ07-320 - 5 GPM 3/4 HP SQ-Series Deep Well Submersible Pump (320' Rated Head) (2W - 200-240V)
Model: 96160135
Call 1 (800) 710-7499 for pricing and order information.
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Factory-Direct
Ships in 2-5 Business Days

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Optional Accessories 10
$7.00
Only 4 In-Stock
$17.00
$5.00
Only 2 In-Stock
$5.00
Only 2 In-Stock
$94.00
Only 1 In-Stock
$54.00
In-Stock
$99.99
Factory-Direct
$24.99
$24.99
Only 1 In-Stock

Features

Inlet Size

N/A

Style

Deep Well

GPM

5 Gallons

  • Grundfos 5SQ07-320 - SQ Series 3" Submersible Well Pump (2W - 200-240V)
  • Ideal for use with 3" I.D. or larger boreholes
  • Rated 5 GPM @ 320' Head Lift
  • Please see documents for sizing / pump curve information
  • 3/4 HP Permanent-Magnet (PM) Stainless Steel Motor (2-Wire - 200-240V)
  • Highly-efficient design with thermal overload protection for added safety
  • Fitted with a replaceable cable plug for ease of use
  • Soft Start Design
  • Allows for a low starting current with a smooth and steady acceleration
  • Low current draw helps reduce wear & provides ability to use smaller gauge wire
  • Dry-Running Protection
  • Helps extend pump life by preventing pump damage due to lack of water in well
  • Highly-Efficient Stainless Steel Pump
  • Polyamide reinforced hydraulic pump components for more efficient energy use
  • "Floating" Impellers w/ Tungsten Carbine/Ceramic Bearings
  • Allows for high wear resistance to sand which extends pump life
  • Top-Bearing Upthrust Protection
  • Provides added protection to motor/pump during start-up
  • Overvoltage & Undervoltage Protection
  • Prevents damage to the motor if voltage moves outside rated range
  • Overload Protection
  • Reduces Motor RPM or turns off power to motor to prevent damage to motor
  • Overtemperature Protection
  • Built-in temperature sensor ensures optimum operating conditions for the motor
  • 2-Year Warranty

Specifications

96160135
specs product image PID-80409
General Information
Product Category
Water Pump
Motor
Voltage
240 Volt Single-Phase
Running Amps
8.4
Wire
2-Wire
Thermal Protection
Yes
Pump
Gallons Per Minute
5 Gallons
Outlet Diameter
1 Inch
Self Priming
Yes
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Composite
Total Head Lift
544 Feet
Discharge Port Size
1 Inch
Submersible
Yes
Series
SQ
Engine
Horsepower
0.75 HP
Overview
Product Category
Water Pump
Weight
13 Pounds
Consumer Warranty
2 Years
Product Length
34.9 Inches
Product Width
2.9 Inches
Product Height
2.9 Inches

Reviews

(2)
Grundfos Pumps 96160135 Reviews & Ratings
Good Product
By Michael D.
Maxwell, California
Review Posted 04/20/2021
Good product.
Michael D. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Reliable
Cons:
Expensive
Verified Buyer
Verified Buyer
Works Fine
By Paul B.
Montgomery, Texas
Purchased 05/26/2018 |
Review Posted 07/12/2018
The pump works as advertised, and is a good price.
Paul B. Recommends This
Was this review helpful?
Rating Breakdown
Features
4/5
icon-review-marker
Quality
4/5
icon-review-marker
Performance
4/5
icon-review-marker
Value
4/5
icon-review-marker
Pros:
Quiet, Price, Reliable, High Quality
