Grundfos 22SQE10-190 - 22 GPM 1 HP SQE-Series Deep Well Submersible Pump (190' Rated Head) (2W - 200-240V)

Model:

96160200

Write A Review
Grundfos 22SQE10-190 - 22 GPM 1 HP SQE-Series Deep Well Submersible Pump (190' Rated Head) (2W - 200-240V)
Grundfos 22SQE10-190 - 22 GPM 1 HP SQE-Series Deep Well Submersible Pump (190' Rated Head) (2W - 200-240V)
Model: 96160200
Call 1 (800) 710-7499 for pricing and order information.
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Factory-Direct
Ships in 2-5 Business Days

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Optional Accessories 8
$4.00
Only 5 In-Stock
$99.99
Factory-Direct
$315.00
$108.00
$519.00
$24.99
Only 3 In-Stock
$24.99
Only 3 In-Stock

Features

Inlet Size

N/A

Style

Deep Well

GPM

22 Gallons

  • Grundfos 22SQE10-190 - SQE Series 3" Submersible Well Pump (2W - 200-240V)
  • Ideal for use with 3" I.D. or larger boreholes
  • Rated 22 GPM @ 190' Head Lift
  • Please see documents for sizing / pump curve information
  • *Requires Grundfos CU 301 Constant Pressure Kit (Not Included) (Model 96438895)
  • Constantly adapts pump performance to meet the demand for water
  • Can provide constant water pressure from 40 -100 PSI
  • 1 HP Stainless Steel Grundfos "Smart Motor" (2-Wire - 200-240V)
  • Variable-speed, electronically controlled, communicates with CU 301 status box
  • Highly-efficient Permanent-Magnet (PM) design w/ Thermal overload protection
  • Soft Start Design
  • Allows for a low starting current with a smooth and steady acceleration
  • Low current draw helps reduce wear & provides ability to use smaller gauge wire
  • Dry-Running Protection
  • Helps extend pump life by preventing pump damage due to lack of water in well
  • Highly-Efficient Stainless Steel Pump
  • Polyamide reinforced hydraulic pump components for more efficient energy use
  • "Floating" Impellers w/ Tungsten Carbide/Ceramic Bearings
  • Allows for high wear resistance to sand which extends pump life
  • Top-Bearing Upthrust Protection
  • Provides added protection to motor/pump during start-up
  • Overvoltage & Undervoltage Protection
  • Prevents damage to the motor if voltage moves outside rated range
  • Overload Protection & Overtemperature Protection
  • Reduces Motor RPM or turns off power to motor to prevent damage to motor
  • Built-in temperature sensor ensures optimum operating conditions for the motor
  • Grundfos GO Remote Compatible (Sold Separately)
  • Lets you configure, control and alter pump settings with your Android/IOS device
  • 2-Year Warranty

Specifications

96160200
specs product image PID-80395
General Information
Product Category
Water Pump
Motor
Voltage
240 Volt Single-Phase
Running Amps
11.2
Wire
2-Wire
Thermal Protection
Yes
Pump
Gallons Per Minute
22 Gallons
Outlet Diameter
1-1/2 Inch
Self Priming
Yes
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Composite
Total Head Lift
292 Feet
Discharge Port Size
1-1/2 Inch
Submersible
Yes
Series
SQE
Engine
Horsepower
1 HP
Overview
Product Category
Water Pump
Weight
16 Pounds
Consumer Warranty
2 Years
Product Length
38.2 Inches
Product Width
2.9 Inches
Product Height
2.9 Inches

Reviews

(3)
Grundfos Pumps 96160200 Reviews & Ratings
Verified Buyer
Verified Buyer
First Impressions Only...
By Jon S.
Schoolcraft, Michigan
Purchased 03/16/2020 |
Review Posted 04/18/2020
I have personally owned Grundfos products before with trouble-free performance which is why I purchased Grundfos again. This particular pump is not yet installed but an out of the box review can provide a few insights:

1. Pump outlet is 1.5". That's great to miminize frictional pressure losses down the line. However, be prepared to pay a significant upcharge for your 1.5" Pitless. You can adapt it down to the more common 1.25", but then you have a restriction again. Depends how pure you want to be with your pipe sizing.

2. Obviously well built and appears to be a typical submerged / deep well pump Grundfos style installation. You must use the CU-301 series controller for this pump to work. I've had my personal household Grundfos system for 18+ years without a single problem. Make sure you follow the latest electrical code, especially for proper system and bonding grounds - it may just save your system during a lightning strike.

3. Shipping could've been better. I received the pump in the factory packaging and one of the taped ends had the tape worn/cut through so that only the styrofoam end was keeping the pump from falling out. A little extra packing / inspection prior to shipping would've helped here.

All in all, I'm very satisfied so far.
Jon S. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Durable, Quiet, Reliable, Id Buy It Again
Cons:
Packaging, Expensive
Verified Buyer
Verified Buyer
So Far So Good
By Dan S.
Kuna, Idaho
Purchased 10/11/2019 |
Review Posted 11/14/2019
So far the pump has worked great. It was easy to install and puts out a lot of water!
Dan S. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Quiet
Verified Buyer
Verified Buyer
Works Perfectly!
By Tyler P.
Boise, ID, Idaho
Purchased 07/02/2019 |
Review Posted 07/23/2019
Installed with 1 1/4ā€ drop pipe. Filled a Five gallon bucket in 10 seconds. 30 gal per min šŸ˜
Tyler P. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
4/5
icon-review-marker
Pros:
Easy To Use, Exceeded Expectations, High Quality, I'd Buy It Again
Cons:
Expensive
