Industrial Air 5.7-HP 60-Gallon Single Stage Air Compressor (230V 1-Phase)
Model:
ILA5746080
+
Share This Product
Similar Products
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
7
Model: TRI-GD-1100P-GL
$65.00
Factory-Direct
Model: TRI-GD-2100P-GL
$95.00
Factory-Direct
Model: DH420000AV
$49.00
Factory-Direct
Model: DXCM024-0400
$209.00
Factory-Direct
Model: 072-0030IA
$107.99
Factory-Direct
Model: BG1006-4
$15.99
Factory-Direct
$783.33
Factory-Direct
Features
Grade
Consumer
Style
Single Stage 1-Phase
CFM
18.1
Tank Size
60
- High Air Flow Single-Stage Compressor
- Produces 18 CFM @ 90 PSI to run many different air tools
- Cast Iron 3 Cylinder Pump
- Durable, one piece cast-iron crankcase & full cylinder body
- TOPS® Motor (Thermal Overload Protection System)
- Protects the motor from voltage fluctuations
- Oil Lubricated
- Swedish stainless steel flex leaf valves for optimum performance
- Shipped with synthetic oil for best performance & long pump life
- Easy fill access & oil sight glass make maintenance simple
- 16" Balanced Cast Iron Flywheel
- Belt drive is smoother & quieter than direct-drive units
- Large Intake Filter/Silencer
- Provides good air flow & reduces noise
- Low Profile 60 Gallon ASME Certified Air Receiver
- Longer run times on air tools such as ratchets, impacts, etc.
- Less top heavy than traditional vertical compressors
- Maximum pressure 155 PSI; 230V-1 phase power required
- Factory Warranty
- 1 year for residential use; 90 days for commercial use
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
ILA5746080
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
5.5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
18.1
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
60 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
385 Pounds
Certification
CSA
Consumer Warranty
1 Year
Commercial Warranty
90 Days
Product Length
26 Inches
Product Width
37 Inches
Product Height
62.5 Inches
Power Type
Electric
UPC
846212002698
Reviews
(4)
Industrial Air ILA5746080 Reviews & Ratings
Verified Buyer
Update / Follow Up
By Eric K.
DeSoto, Wisconsin
Purchased 04/27/2019 |
Review Posted 06/12/2019
I already wrote a review, but I keep getting e-mails to write a review...there were a few more things I wanted to mention, so ok.
It's been about a month and a half and my unit is still running top-notch, I did the " no no " of changing the pressure switch kick-off point, but I figured it was ok because I lowered it to 130psi, not increased it, because I am still on the 20A temporary construction breakout.
It looks like they came out with a new drive guard, I like the look of the new style, and wonder if it's easier to do belt adjustments with the new style guard...
I did an initial belt adjustment. Don't assume any air compressor comes from the factory with the drive system properly aligned and I generally error a touch to the slack side of the tension spec in favor keeping the belt and pullies clean, because I would rather change a belt than have my motor drive side bearing fail. ( possibly causing sparks in the motor )
This compressor has stainless steel valves, but not stainless steel valve plates, so the review there a victim of humid air, which, in Wisconsin, makes me feel like that may become a service interval at some point for me also.
Just make sure you do your initial drive belt alignment and a textbook or better break in, or problems will crop up much sooner than later.
Still no problems here.
It's been about a month and a half and my unit is still running top-notch, I did the " no no " of changing the pressure switch kick-off point, but I figured it was ok because I lowered it to 130psi, not increased it, because I am still on the 20A temporary construction breakout.
It looks like they came out with a new drive guard, I like the look of the new style, and wonder if it's easier to do belt adjustments with the new style guard...
I did an initial belt adjustment. Don't assume any air compressor comes from the factory with the drive system properly aligned and I generally error a touch to the slack side of the tension spec in favor keeping the belt and pullies clean, because I would rather change a belt than have my motor drive side bearing fail. ( possibly causing sparks in the motor )
This compressor has stainless steel valves, but not stainless steel valve plates, so the review there a victim of humid air, which, in Wisconsin, makes me feel like that may become a service interval at some point for me also.
Just make sure you do your initial drive belt alignment and a textbook or better break in, or problems will crop up much sooner than later.
Still no problems here.
Eric K. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, Fast, Quiet, Reliable
Cons:
none
Best Air Compressor I Have Ever Owned
By Eric K.
De Soto, Wisconsin
Review Posted 05/08/2019
This was the only vertical air compressor, with the needed performance specs, that would fit under the upper gangway in the shop I am building... I think the short chubby tank, in a powerful vertical, was a really good move by Industrial Air
I wired in a 30 amp plug on 12/3 SJ and took it through the half hour break in..then I drained the pump and reloaded it with 30W air compressor oil, and ran a second half-hour break-in/flush.
Then I took the drain plug off the drain pipe, (because the whole pipe kept coming out ), put a 3/8 NPT elbow on the oil drain pipe with JB-Weld tipped the compressor back, cleaned the threads, and put JB-Weld on those threads also, then tightened it to about 60 ft.lbs.,and got a 3/8" pipe plug to go up into the elbow...
Put in some fresh full synthetic 30W non-detergent, and took it up to 100psi, (because I am on just a 20A double pole at the moment ), and shut it off...3 hours later it was still at 100psi...
Fairly smooth, and very strong compressor...It loads the tank quickly and I can't wait to get it off the temporary construction break out and onto its own 30A...
Thanks Air Compressors Direct.
I wired in a 30 amp plug on 12/3 SJ and took it through the half hour break in..then I drained the pump and reloaded it with 30W air compressor oil, and ran a second half-hour break-in/flush.
Then I took the drain plug off the drain pipe, (because the whole pipe kept coming out ), put a 3/8 NPT elbow on the oil drain pipe with JB-Weld tipped the compressor back, cleaned the threads, and put JB-Weld on those threads also, then tightened it to about 60 ft.lbs.,and got a 3/8" pipe plug to go up into the elbow...
Put in some fresh full synthetic 30W non-detergent, and took it up to 100psi, (because I am on just a 20A double pole at the moment ), and shut it off...3 hours later it was still at 100psi...
Fairly smooth, and very strong compressor...It loads the tank quickly and I can't wait to get it off the temporary construction break out and onto its own 30A...
Thanks Air Compressors Direct.
Eric K. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, Quiet, Fast, Reliable
Cons:
none
Bad electric motors
By Scott H.
Wray, Colorado
Review Posted 11/16/2014
I had this air compressor for six months. It worked great until the electric motor shot sparks out and stopped working. Industrial Air warrantied the motor. Took two weeks to get it. Now after four months this motor acts as if it barely has enough power to run the pump. I'm not happy with this product. DO NOT BUY this compressor.
Scott H. Does Not Recommend This
Was this review helpful?
Expert Response
We are sorry to hear of the issue you are having with your compressor. Your best option would be to contact Industrial Air, the manufacturer. The manufacture and warranty the product and would be better suited to help with and issue such as this. You can reach Industrial Air at (888) 895-4549.
Dale V.
Power Equipment Expert
Rating Breakdown
4/5
1/5
2/5
1/5
Pros:
Price
Cons:
Low Quality
Compressor not working
By Mac McD.
Burlington, Kansas
Review Posted 04/30/2014
Had compressor for one year and it worked well and air volume was excellent. Quit pumping on one cylinder and found that all the valve plates were rusted and valve not sealing. Cannot find parts.
Mac McD. Does Not Recommend This
Was this review helpful?
Expert Response
You may want to give the folks at Industrial Air a call, toll free at (888) 895-4549 to see if they have parts available. Please be sure to have the serial number of the air compressor handy when you call; they will probably ask for it.
This unit has a 1 year Factory Warranty, and it sounds like you may be nearing or past the end of that period. The warranty starts the day the unit was delivered if you ordered it online; or from the date of purchase if you bought it locally. I checked our files by your email address and didn't see a listing for you; I'm sorry I can't tell if the unit is still covered.
This unit has a 1 year Factory Warranty, and it sounds like you may be nearing or past the end of that period. The warranty starts the day the unit was delivered if you ordered it online; or from the date of purchase if you bought it locally. I checked our files by your email address and didn't see a listing for you; I'm sorry I can't tell if the unit is still covered.
Dale V.
Power Equipment Expert
Rating Breakdown
5/5
2/5
1/5
5/5
Pros:
Quiet, Price, Fast
Cons:
Unreliable, Durability, Valve Plate Is Carbon Stell And Rust Prevents Valves From Sealing
