Ingersoll Rand Type 30 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)
Model:
2340L5.230-1
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
1
These accessories are required to properly setup/install this product.
Model: 47853635004-R
Frequency
Frequency
Select how often you will receive your air filters, we offer many options to meet your air quality standards.
Quantity
Quantity
This will be how many filters you receive per delivery.
Quantity
$169.99
In-Stock
Optional Accessories
13
Model: 21999-0177
$109.80
In-Stock
Model: 32321002
$19.25
Factory-Direct
Model: TRI-GD-1100P-GL
$65.00
Factory-Direct
Model: TRI-GD-2100P-GL
$95.00
Factory-Direct
$191.00
Factory-Direct
$1,949.99
Model: DXCM024-0400
$209.00
Factory-Direct
Model: FA40IH
$231.99
In-Stock
$235.00
Only 4 In-Stock
Model: 38335402
$395.00
Factory-Direct
$44.00
Factory-Direct
Model: 22890214
$1,763.00
Factory-Direct
Model: 23474653
$160.00
Factory-Direct
Features
Grade
Consumer
Voltage
230 Volt AC
Phase
1-Phase
CFM
14
Tank Size
60
Ingersoll Rand Type 30 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- Continuous-Duty Operation
- 100% cast-iron cylinders and pump
- Oversized cast-iron balanced belt wheel
- Oversized industrial-grade bearings
- High Efficiency Parts
- High-efficiency stainless steel valves
- High-efficiency intercooler
- High-efficiency inlet air filters with sound attenuation baffles
- 2-Piece Connection Rods
- Less moving parts increases reliability
- High-Efficiency Intercooler
- Lowers compressed air temperature and reduces condensation
- OSHA Compliant
- Fully enclosed flywheel, belt and motor sheave
- Fully Tested
- All units are prewired and thoroughly tested prior to shipment
- 1-Year Warranty (Unit Ships Dry)
- 1 or 2-year extended warranty available with purchase of IR Start Up Kit at time of purchase (See Accessories)
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
2340L5.230-1
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
28
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
14
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Overview
Product Category
Air Compressor - Stationary
Weight
435 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31.5 Inches
Product Width
33 Inches
Product Height
69 Inches
Power Type
Electric
UPC
678384649223
Reviews
(58)
Ingersoll Rand 2340L5.230-1 Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.29
(57 Ratings)
5
(32)
(32)4(13)
(13)3(9)
(9)2(2)
(2)1(1)
(1)
Ingersoll Rand has been a quality name since your grandfather's time- with good reason. Since 1905 they have been building tools that stand the test of time. What you get for the money is a durable, reliable air compressor with high-efficiency valves, air filters, and intercooler; along with OSHA compliant housing on the flywheel, belt, and motor sheave.
An oversized belt wheel and bearings allow for continuous duty operation with less time off for wear and tear repairs. Ingersoll Rand units might take a little longer to ship out than other brands, but we believe it's worth it since they pre-wire and thoroughly test each unit before it's crated up.
An oversized belt wheel and bearings allow for continuous duty operation with less time off for wear and tear repairs. Ingersoll Rand units might take a little longer to ship out than other brands, but we believe it's worth it since they pre-wire and thoroughly test each unit before it's crated up.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Brand that is starting to decline.
By Ken W.
Massachusetts
Purchased 12/26/2024 |
Review Posted 01/30/2025
My review has no poor reflection on Air Compressor Direct. Purchased an Ingersoll Rand because of their notoriaty and dependability. Installed the unit and performed start up. Had an air leak at fitting on top of tank. Warranty service tech determined not enough sealant used at factory. He told me that the company pushes so many units out, they don't test units before shipping. Tech removed fitting, cleaned, and Teflon taped to repair leak. In full disclosure, my current compressor is my 2nd Ingersoll Rand I purchased but from another supplier. On my first, the motor needed to be replaced under warranty, and then the pump failed out of warranty. A screw came undone internally, causing pump to be damaged. Repair cost was close enough to the cost of a new compressor, which brought me to my current compressor. That is why I feel the brand is starting to decline. Buyer beware.
Ken W. Does Not Recommend This
Was this review helpful?
Rating Breakdown
5/5
4/5
5/5
4/5
Pros:
Easy To Use, Features
Cons:
Low Quality
So Far So Good
By James C.
Pennsylvania
Purchased 06/24/2024 |
Review Posted 08/17/2024
Great price, fast shipping, delivery went perfect, and the driver went above and beyond.
James C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Morons & Junk Flywheel
By Tom N.
Colorado
Purchased 05/27/2024 |
Review Posted 07/30/2024
What a piece of junk. The entire compressor head is cast over an open campfire in India. When I received the unit and fired it up, it danced all over the floor because of a severely out-of-balanced flywheel. I contacted your "expert' Melissa and she immediately threw me under the bus and told me to contact the service center in Aurora CO which just happens to be across the entire state of Colorado. After many repeated tries to contact them, I told them what I thought was wrong. Their solution was to send the entire top heavy compressor across the entire state of Colorado so they could look at it. I told them I wasn't about to take a chance on freight company damage to the unit both ways. They refused to send a tech to look at the unit where I live. In fact, Michael the guy in Aurora wouldn't even answer my email. What a bunch of Morons! I ordered a new flywheel at my expense, $259.00, and fixed the unit myself, while it was still under warranty. Their warranty should be printed on toilet paper, then it would be good for something! I wouldn't recommend IR compressors or this outfit to my worst enemies!
Tom N. Does Not Recommend This
Was this review helpful?
Expert Response
First and foremost, thank you for your purchase. We are sorry to hear you are having issues with your unit. Our company is required to follow the manufacturer warranty process if there are issues. We will forward your review to the manufacturer so they are aware of the situation.
We appreciate your business and apologize for any inconvenience.
We appreciate your business and apologize for any inconvenience.
Dale V.
Power Equipment Expert
Rating Breakdown
1/5
1/5
1/5
1/5
Car Wash
By Adam S.
California
Purchased 06/21/2024 |
Review Posted 07/14/2024
I have been using it in the car wash for years. This is another addition and probably one more to order.
Adam S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Cons:
None
Cadillac
By Gary B
Louisiana
Purchased 04/11/2023 |
Review Posted 05/29/2023
1 st. Class compressor so far not many hrs on it yet but so far, well satisfied. For the $ it should have come with a site glass to see the oil level other then that can’t say much more on it now.
Gary B Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
Heavy, Bad Instructions
Quit Working After Two Months
By Kevin
Alaska
Purchased 01/10/2023 |
Review Posted 03/24/2023
Do not buy!
Kevin Does Not Recommend This
Was this review helpful?
Expert Response
Very sorry to hear you're having problems with your air compressor. IR provides a 1-Year Warranty on this model. For warranty support, IR can be reached directly at 800-483-4981.
Dale V.
Power Equipment Expert
Rating Breakdown
3/5
1/5
1/5
1/5
Good Machine
By Dave T
New York
Purchased 12/31/2022 |
Review Posted 03/07/2023
Only issue was overpressure valve leaked due to it never being properly tightened at factory. I pulled it out wiped off their dope, Teflon taped it and sent it home. Does not require a lot of torque to seal but it was not much more than finger tight. I added an Eaton 5ho mag start because the cheap pressure switches they use will burn out they’re not designed for that type of power. Also will add oil drain plug with sight glass at compressor oil change. Picture was after wiring but before piping but ran 3/4 copper (pro press) with access tees for full pressure before feeding regulator/filter/dryer and hose reel. Works great good value of it holds up.
Dave T Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
5/5
5/5
Pros:
Easy To Use, Price
Good For Most Part
By Andrew S
Ohio
Review Posted 12/26/2022
Air compressor showed up Undamaged to the eye so that was good. When I got it home I combed thru it more. I found that the 1/2” ball valve was very hard to shut all the way and since I like to shut all air off at night didn’t want the hassle so I replaced that with one I had. Wasn’t impressed that it didn’t have an oil sight glass but I knew that before I bought it and added one also. Checked the air filter element and it appears that they didn’t get it placed correctly from factory and the backside was on bracket and deformed filter rubber gasket. So now I’m worried that if I don’t replace it will suck dust/dirt in and jeapordize the life span of my compressor. I need to call them and see if they can send me a replacement
Andrew S Recommends This
Was this review helpful?
Expert Response
For technical support, IR can be reached directly at 800-483-4981
Dale V.
Power Equipment Expert
Rating Breakdown
3/5
3/5
4/5
3/5
Pros:
Easy To Use, I'd Buy It Again
Cons:
Expensive
RGX Rim Repair
By Gerald G
IL
Review Posted 09/20/2022
Compressor works splendidly. Great quality and value.
Gerald G Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, I'd Buy It Again
Cons:
None
Perfect Fit For Our Needs
By Steve M.
Veradale, Washington
Purchased 01/19/2022 |
Review Posted 02/11/2022
We were in need of an air compressor to replace our existing one that was becoming tired and not keeping up with our users needs. Shopped around looking for a replacement and found this compressor. Another big factor for me was, they had it in stock, which was huge as we needed it asap!. First impressions are, it is a well built machine, and so far, looks to be exceeding our needs. Good product, would buy again and recommend.
Steve M. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
Pros:
Fast, Price, High Quality, Exceeded Expectations
Product Q&A
(3)
Product Questions
Answered by Melissa, the Air Compressor Expert
What RPM does the electric motor run?
John G.
from Georgia
July 29, 2019
What is the advantage of a 2 stage unit versus a single stage unit on a 5 HP compressor.
Tom
from Illinois
July 31, 2014
I am in Australia and was wondering about using this compressor over here. Do you know if it is compatible. Do you have the specs so that I can check with the electricians over here. Thanks for your help.
Cristos Zisopoulos
from
December 04, 2011
