Ingersoll Rand Type 30 7.5-HP 80-Gallon Two-Stage Air Compressor (230V 3-Phase)
Model:
2475N7.5-230
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
1
These accessories are required to properly setup/install this product.
Model: 47853635004-R
Frequency
Frequency
Select how often you will receive your air filters, we offer many options to meet your air quality standards.
Quantity
Quantity
This will be how many filters you receive per delivery.
Quantity
$169.99
In-Stock
Optional Accessories
12
Model: 21999-0177
$109.80
In-Stock
Model: 32321002
$19.25
Factory-Direct
$41.00
Factory-Direct
$2,449.00
Model: FA75IH
$306.99
In-Stock
$306.99
Only 3 In-Stock
Model: R37451-600
$219.00
Factory-Direct
Model: 38335410
$399.00
In-Stock
$44.00
Factory-Direct
Model: 22890214
$1,763.00
Factory-Direct
$219.99
In-Stock
$783.33
Factory-Direct
Features
Grade
Commercial
Voltage
230 Volt AC
Phase
3-Phase
CFM
24
Tank Size
80
- Continuous-Duty Operation
- 100% cast-iron cylinders and pump
- Oversized cast-iron balanced belt wheel
- Oversized industrial-grade bearings
- High Efficiency Parts
- High-efficiency stainless steel valves
- High-efficiency intercooler
- High-efficiency inlet air filters with sound attenuation baffles
- 2-Piece Connection Rods
- Less moving parts increases reliability
- High-Efficiency Intercooler
- Lowers compressed air temperature and reduces condensation
- OSHA Compliant
- Fully enclosed flywheel, belt and motor sheave
- Fully Tested
- All units are prewired and thoroughly tested prior to shipment
- 1-Year Warranty (Unit Ships Dry)
- 1 or 2-year extended warranty available with purchase of IR Start Up Kit at time of purchase (See Accessories)
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
2475N7.5-230
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
230 Volt AC
Phase
3-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
Yes
Amp Draw
22
Recommended Breaker
Consult Certified Electrician
Engine
HP
7.5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
24
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Overview
Product Category
Air Compressor - Stationary
Weight
611 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
48 Inches
Product Width
40 Inches
Product Height
76 Inches
Power Type
Electric
Additional Model Numbers
2475N7.5-230, 2475N7.5-230
Reviews
(9)
Ingersoll Rand 2475N7.5-230 Reviews & Ratings
Customer Photos and Videos
This Ingersoll Rand 2-stage unit is a workhorse, designed for locations with three-phase power. That makes it great for heavy shop or industrial use since it can handle high-demand tools like sanders and impact wrenches with ease.
The cast-iron pump & belt wheel will provide reliable service year after year. We like that Ingersoll Rand pre-wires and tests each unit before it ships- making sure you get the dependable, durable air compressor you expect.
The 7.5-HP 80-Gallon air compressor will provide the reliability and performance for all sorts of applications including automatovie service and body shops, fleet maintenance, and production and manufacturring line with the precision engineered components.
The cast-iron pump & belt wheel will provide reliable service year after year. We like that Ingersoll Rand pre-wires and tests each unit before it ships- making sure you get the dependable, durable air compressor you expect.
The 7.5-HP 80-Gallon air compressor will provide the reliability and performance for all sorts of applications including automatovie service and body shops, fleet maintenance, and production and manufacturring line with the precision engineered components.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Ingersoll compressor
By John
California
Review Posted 11/05/2024
I see some negative comments especially one about a plug that was jammed as he says. Sounds like the end of the world. Reviews are supposed to be subjective and something that sounds like taking one’s frustration out. One little plug that he should have checked out before installing the unit. All the way to one star?? Needs to grow up. I have been using mine for 15 years without any issues. I have owned several different brands and types of compressors.
John Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, I39d Buy It Again
Cons:
Expensive parts.
What A Disaster To Be Polite
By Alberto B.
Minneapolis, Minnesota
Purchased 11/10/2020 |
Review Posted 12/08/2020
Bottom screw on Fitting was jammed in, leaking and blew out under pressure... nobody got hurt, thank God. That off course happened after the unit was completely installed, all plumbing, electrical etc...
Assembled in America, well, there we go, total miss, no Quality Control and truly dangerous I will go out of my way to never buy a Product from those Scammers again.
Assembled in America, well, there we go, total miss, no Quality Control and truly dangerous I will go out of my way to never buy a Product from those Scammers again.
Alberto B. Does Not Recommend This
Was this review helpful?
Expert Response
Hello Alberto, we appreciate you taking the time to provide us with your feedback and we can certainly understand your aggravation. We are sincerely sorry for the issue you are having with your new compressor. Factory Warranties cover defects in materials and workmanship. The IR folks are the best equipped to get the problem corrected promptly and they can be reached directly at 800-483-4981.
If their service doesn't meet your expectations, or if there's anything else we can do to help please give me a call directly us 866-437-8002.
If their service doesn't meet your expectations, or if there's anything else we can do to help please give me a call directly us 866-437-8002.
Dale V.
Power Equipment Expert
Rating Breakdown
1/5
1/5
1/5
1/5
Cons:
Low Quality, Unreliable
Gasko Fabricated Products
By Randy G.
Medina, Ohio
Purchased 05/19/2015 |
Review Posted 07/30/2015
After two hours run time the compressor quit working. They came and replaced some internal valves in the pump. Two days later same thing. To make long story short they replaced the pump, so far so good.
Randy G. Does Not Recommend This
Was this review helpful?
Expert Response
Sorry to hear about the trouble with the new IR compressor. But glad to hear that IR has replaced the pump.
Dale V.
Power Equipment Expert
Manufacturer Response
I apologize for the inconvenience you had associated with your purchase. I want to make sure that you are 100% satisfied with your purchase. Please feel free to contact me directly if there is anything else I can do to make sure that you have absolutely no issues with your machine. Thank you for your purchase!
Best Regards,
Kevin Rohner
Sales Manager, Ingersoll Rand
Best Regards,
Kevin Rohner
Sales Manager, Ingersoll Rand
Rating Breakdown
2/5
2/5
2/5
2/5
The old compressor finally laid down
By James K.
pampa, Texas
Purchased 03/26/2014 |
Review Posted 05/08/2014
I had an old Ingersoll compressor at my shop... it finally laid down. Got the new Ingersoll and what a difference in the CFMs!
James K. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Reliable, High Quality, I'd Buy It Again
Cons:
Didnt Come With Oil
Nice GSA buying experience
By Kurt
Casper, Wyoming
Purchased 05/22/2013 |
Review Posted 06/17/2013
Just got it installed. Nice compressor, very good price, GSA contract pricing made the purchase simple.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Very good recovery time
By Adrian
Nebraska
Purchased 03/26/2013 |
Review Posted 05/10/2013
Very good recovery time, & easy installation- I would recommend to others.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Car wash power
By Scott
Rock Port, Missouri
Purchased 01/26/2013 |
Review Posted 02/16/2013
I had run my car wash with a single phase, single stage 60 gallon compressor for the past five years, having to rebuild the pump twice and replaced it once.
I went with this larger compressor and so far it's much quicker to recover, runs much less and hopefully will result in lower utility costs.
The only thing I hadn't considered was the additional pressure and the impact it would have on all of my other regulators on the equipment. After the damage was done I bought a 3/4 in and out regulator and adjusted it to 120 psi.
Now the compressor recovery time is even less and the other regulators like it much better. Not thinking of that beforehand was an expensive error on my part. The overload starter protector appeared to be defective but after several jabs with my finger it started up and has been trouble free since.
I would recommend this compressor if you need this amount of air on a consistent basis.
I went with this larger compressor and so far it's much quicker to recover, runs much less and hopefully will result in lower utility costs.
The only thing I hadn't considered was the additional pressure and the impact it would have on all of my other regulators on the equipment. After the damage was done I bought a 3/4 in and out regulator and adjusted it to 120 psi.
Now the compressor recovery time is even less and the other regulators like it much better. Not thinking of that beforehand was an expensive error on my part. The overload starter protector appeared to be defective but after several jabs with my finger it started up and has been trouble free since.
I would recommend this compressor if you need this amount of air on a consistent basis.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Kinda let down :(
By Russ B.
Sanford, Florida
Purchased 06/07/2012 |
Review Posted 08/10/2012
Ive always bought IR compressors because of the quality build. This 7.5/80 I bought has an incomplete weld around the main bulkhead on the front of the tank and leaks from a small pin hole.
With about a week of run time on it the flywheel bolts came lose and made a hell of a racket until i figured out where the sound was coming from.
I run 3 shifts a day and cannot take the compressor down for any length of time so I run it with a leaky tank. I tried contacting the rep in Central Florida and never got through- no answering machine or nothing .
Very depressing for me after being a solid customer with high standards :(
Anyone have a valid contact number for Florida reps ?
With about a week of run time on it the flywheel bolts came lose and made a hell of a racket until i figured out where the sound was coming from.
I run 3 shifts a day and cannot take the compressor down for any length of time so I run it with a leaky tank. I tried contacting the rep in Central Florida and never got through- no answering machine or nothing .
Very depressing for me after being a solid customer with high standards :(
Anyone have a valid contact number for Florida reps ?
Was this review helpful?
Expert Response
We've emailed you directly with the 800 number to contact Ingersoll (800) 866-5457). They will have the most recent contact information for warranty service in your area.
Dale V.
Power Equipment Expert
Rating Breakdown
3/5
3/5
3/5
3/5
