Iron & Oak 22-Ton Honda Powered Horizontal / Vertical Gas Log Splitter

Model:

BHVH2213GX

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Iron & Oak 22-Ton Honda Powered Horizontal / Vertical Gas Log Splitter
Iron & Oak 22-Ton Honda Powered Horizontal / Vertical Gas Log Splitter
Model: BHVH2213GX
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

  • Split Wood In Horizontal Or Vertical Positions
  • Split smaller logs at comfortable waist height
  • Switch to vertical, save your back & roll large logs into place
  • E-Z lift hinge - one hand lift to vertical operation
  • Reliable Honda GX160 4-Cycle Gas Engine
  • OHV design for increased efficiency and optimal power transfer
  • Exceptionally quiet; smooth performance
  • 2-Stage Hi-Lo, 11 GPM Hydraulic Pump
  • Productive 12 second cycle time with auto-return
  • 9.5 gallon hydraulic system; hydraulic fluid not included
  • High pressure hoses on both the pressure & return side
  • 7-Inch High Carbon Steel Splitting Wedge
  • 24.5" log opening on 6" heavy-duty formed steel beam
  • 34-inch working height from ground to top of beam
  • Log Dislodger included ($84 retail value)
  • High Speed 4.80 x 8 Highway Rated Tires
  • Heavy duty steel fenders
  • Factory Tested
  • All major components & hydraulic tank tested before shipment
  • Made In U.S.A.
California residents see
Warning: This product can expose you to chemicals including Carbon monoxide which is known to the State of California to cause Developmental Harm, and Soots, tars, and mineral oils (untreated and mildly treated oils and used engine oils) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

BHVH2213GX
specs product image PID-13315
Engine
Engine Brand
Honda GX
Starting System
Recoil Start
HP
4.8 HP
CC
163 CCs
Fuel Tank Size
0.75 Gallons
Low Oil Shutdown
Yes
Hydraulics
Auto Return
Yes
Hydraulic Filter
Yes
Hydraulic Oil Included
No
Hydraulic Reservoir Size
9.5 Gallons
Cylinder Diameter
4 Inches
Cylinder Length
24 Inches
Cycle Time
12 Seconds
Tonnage
22 Tons
Overview
Assembly Required
Yes
Weight
635 Pounds
Consumer Warranty
1 Year
Wedge
Wedge Material
Steel
Wedge Size
7 Inches
Wedge Style
2-way
Replaceable Wedge
Yes
Sharpenable Wedge
Yes
Log Capacity
Max Log Length
25 Inches
Towing
Towable
Yes
D.O.T. Lights
Sold Separately
Fenders
Included
Hitch Type
2 Inch Ball Hitch
Max Towing Speed
45 MPH
Accessories
Jack Stands
Included
Log Cradles
Sold Separately
Wood Type Hardness Rating 6" Seasoned 6" Green 12" Seasoned 12" Green 24" Seasoned 24" Green
Alder 590 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Ash 1320 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Aspen 420 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Basswood 410 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Beech 1300 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Birch 1470 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Boxelder 720 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Buckeye 350 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Catalpa 550 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Cedar 900 Lbs. 6+ Tons 8+ Tons 15+ Tons 20+ Tons 27+ Tons 30+ Tons
Cherry 950 Lbs. 6+ Tons 8+ Tons 15+ Tons 20+ Tons 27+ Tons 30+ Tons
Cottonwood 430 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Dogwood 2150 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Elm 1540 Lbs. 10+ Tons 13+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Fir 710 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Hickory 1820 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Locust 1700 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Magnolia 1020 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Maple 1450 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Oak 1620 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Pine 860 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Poplar 540 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Spruce 510 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Sweet Gum 850 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Walnut 1010 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
