Kohler Command Pro CH750 747cc 27 Gross HP Electric Start Horizontal Engine, 1-1/8" x 4" Crankshaft, Tapped 7/16"-20 With PTO Drive Shaft (W/ Muffler)
Model:
PA-CH750-3054
+
Share This Product
Features
- Model# CH750-3054, 1-7/16" x 4.46" Crankshaft, Tapped 5/8"-18 With PTO Drive Shaft
- Includes thrust bearing for forward/reverse load pushing on the crank
- KOHLER Command PRO CH750 V-Twin Cylinder Air-Cooled 4-Cycle Horizontal Gas Engine
- Produces 41.2 lbs./ft. peak torque- Power levels are stated gross torque per SAE J1998
- Fully Oil Pressurized Hydraulic Valve Lifters
- Push rods stay in constant contact with rocker arms
- Valve train is maintenance free- no adjustments needed
- Overhead Valve Technology
- Provides greater volumetric efficiency and higher compression ratio
- Produces more power, improved fuel economy/cooling, and reduces oil consumption
- Virtually no carbon buildup, reducing overall maintenance costs
- Variable Speed, Mechanical Governor
- Smooth performance, regardless of application or fluctuating demands for power
- Large Capacity In-Line Fuel Filter And Dual Element Air Filter
- Extra protection against dirt particles that can clog fuel lines
- Maximizes engine power and life
- KOHLER Command PRO
- Generates a stronger spark at low cranking speed
- Automatic Compression Release (ACR)
- Allows compression to escape during cranking to reduce pull force
- 12V Electric Starter & 20A Regulated Charging System
- Mechanical Fuel Pump- Gas Tank Not Included
- Side Mount Muffler Inlcuded
Specifications
PA-CH750-3054

Engine
Engine Series
Command Pro
Engine Style
Horizontal
Engine Type
4-Cycle OHV
Cylinders
2
Cooling System
Air
Dry Weight
105 Lbs
CC
747 CCs
HP
27 HP
Max Torque
41.2 Lbs
Cylinder Bore Type
Cast Iron
Bore
3.3 Inches
Stroke
2.7 Inches
Compression Ratio
9.4:1
CARB
Yes
Systems
Charging System
20 Amps
Starting System
12-Volt Key Start
Ignition System
Electronic Spark
Lubrication
Lubrication
Pressurized
Oil Capacity
64 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Twin Barrel
Muffler
Included
Air Cleaner
Dual Element
Fuel Tank
Not Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
1-1/8 x 4 Inch Inch
Crankshaft Type
Straight
Crankshaft Diameter
1-1/8"
Crankshaft Length
4"
Crankshaft End Tapped Size
7/16"-20
Crankshaft Keyway Width
1/4 Inch Inch
PTO Height
6-1/8 Inches
Overview
Weight
105 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Length
14 Inches
Product Width
17.7 Inches
Product Height
22.4 Inches
Dimensions
14 x 17.7 x 22.4
