Lancaster Pump 2-3LST10012-2
Lancaster Pump 2-3LST10012-2
Hover to zoom
1 Of 5

Lancaster Pump 3LST10012-2 - 1 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB

Model:

2-3LST10012-2

Write A Review
$659.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
More On The Way
Estimated Availability December 30, 2024
Shipping to60601

Lancaster Pump 3LST10012-2 - 1 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB
Lancaster Pump 3LST10012-2 - 1 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB
Model: 2-3LST10012-2
$659.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

N/A

Style

Deep Well

GPM

10 Gallons

  • SURVIVOR T-Series 10 GPM 4" Sub. Well Pump (3-Wire 230V)
  • For 4" I.D. or + Wells (<360'); 3-Wire Starting - Control Box Included
  • 1 HP Lancaster HYDRO-FORCE Encapsulated Sub. Motor
  • Continuous duty rated, Capacitor-start induction run (CSIR) - Req. Control Box (Included)
  • Stainless Steel Motor Casing & Splined Shaft End
  • Hermetically sealed, permanently lubricated, for greater heat exchange
  • Built-In Lighting Arrestors & Automatic Reset Overload
  • Provides surge and overhead protection for increased protection
  • 1.25" Stainless Steel Discharge Head, Motor & Cable Support
  • Superior strength and corrosion resistance for maximum life
  • Field replaceable fluted internal check valve & molded jug handles
  • Balanced Teflon® Impregnated Thermoplastic Impellers
  • Reduces overall friction to maximize water flow
  • Fully-Enclosed Thermoplastic Diffusers & Stage Plates w/ SS Wear Surfaces
  • Each stage has separate comp. thrust washer for added protection
  • Heavy wall, High Quality SS Pump Casing & SS Intake Screen
  • Sized inside for perfect stage alignmen; wouldn't snap off during install
  • Stainless Steel Hex Shaft w/ Slotted End For Test Turning
  • Polyurethane bearing (top/end motor shaft) for wear resistance
  • 1 HP HYDRO-FORCE Quick-Disconnect Control Box (230V)
  • Includes 230V relay, start capacitor & 2 ground/cable terminals
  • NEMR 3R Outdoor rated, painted steel enclosure, QD components
  • 3-Year Limited Warranty

Specifications

2-3LST10012-2
specs product image PID-57906
Motor
Voltage
240 Volt Single-Phase
Running Amps
12
Wire
3-Wire
Pump
Gallons Per Minute
10 Gallons
Outlet Diameter
1-1/4 Inch
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
166
Total Head Lift
360 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
1 HP
Overview
Weight
32.9 Pounds
Consumer Warranty
3 Years
Product Length
28.81 Inches
Product Width
3.81 Inches
Accessories
Control Box
Yes

Reviews

Lancaster Pump 2-3LST10012-2 Reviews & Ratings
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.

Product Q&A

(2)
Expert avatar photo
Product Questions Answered by Jim, the Water Pump Expert
Where is the motor manufactured?
John B.
from Pennsylvania
April 19, 2018
Do I need to buy a check valve or anything else with this pump?
Jim
from Connecticut
March 03, 2017
