Little Giant WE20G05P4-21 - 26 GPM 1/2 HP WE-Series Submersible High Head Filtered Effluent Pump (2W - 115V)

Model:

558223

Write A Review
$609.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 3-4 Weeks

Little Giant WE20G05P4-21 - 26 GPM 1/2 HP WE-Series Submersible High Head Filtered Effluent Pump (2W - 115V)
Little Giant WE20G05P4-21 - 26 GPM 1/2 HP WE-Series Submersible High Head Filtered Effluent Pump (2W - 115V)
Model: 558223
$609.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

N/A

Style

Dewatering

GPM

26 Gallons

  • Little Giant WE20G05P4-21 - WE-Series High Head Filter Effluent Pump
  • Ideal for a wide variety of filtered effluent applications
  • 4" Submersible Pump (2-Wire 115V)
  • Can be used with 4" I.D. or larger wells
  • Powered By Industry Standard Franklin Electric Motor
  • Proven superior quality & performance ensuring quiet operation
  • Hex Rubber Bearing w/ Extra-Large Surface
  • Provides shaft stability and multiple flow channels
  • Keeps small particles such as sand away from bearing surfaces
  • Removable, Built-In Check Valve
  • Prevents backflow and ensures system pressure
  • 1-1/4" NPT Thermoplastic Discharge Head
  • Minimizes friction while providing smooth & quiet operation
  • Proven "PPO" Staging
  • Allows for close tolerances and increased performance
  • Thermoplastic Discharge and Motor Brackets
  • Non-Corrosive design allows for increased pump life
  • Stainless Steel Up Thrust Washer
  • Prevents excessive wear in service applications
  • Additional Features
  • Heavy-Duty, 10' SJOW motor stripped leads
  • 2-Year Limited Warranty

Specifications

558223
specs product image PID-93191
General Information
Product Category
Water Pump
Motor
Voltage
120 Volt
Running Amps
10
Wire
2-Wire
Pump
Gallons Per Minute
26 Gallons
Outlet Diameter
1-1/4 Inch
Housing Material
Stainless Steel
Impeller Material
Plastic
Handles Solids
Yes
Maximum PSI
48
Check Valve Included
Yes
Max Head
150 Feet
Submersible
Yes
Engine
Horsepower
0.5 HP
Overview
Product Category
Water Pump
Weight
25 Pounds
Consumer Warranty
2 Years
Product Length
23.91 Inches
Product Width
3.75 Inches
Product Height
3.75 Inches
UPC
010121118300
