Little Giant 10C1-05P4-2W115 - 10 GPM 1/2 HP Stainless Steel Submersible Effluent / Cistern Pump (2W - 115V) (225' Shut-Off)

Model:

90301005

Write A Review
$539.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days

Little Giant 10C1-05P4-2W115 - 10 GPM 1/2 HP Stainless Steel Submersible Effluent / Cistern Pump (2W - 115V) (225' Shut-Off)
Little Giant 10C1-05P4-2W115 - 10 GPM 1/2 HP Stainless Steel Submersible Effluent / Cistern Pump (2W - 115V) (225' Shut-Off)
Model: 90301005
$539.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

N/A

Style

Dewatering

GPM

10 Gallons

  • Franklin Electric - 10C1-05P4-2W115 - 1/2 HP Submersible Cistern Pump (115V)
  • For gray water, filtered effluent service and water reclamation applications
  • For rain catchment basins, aeration, pond/fountain and livestock water pumping
  • 3.9" Submersible Pump (2-Wire 115V)
  • 10 GPM - 225' Shut-Off Head
  • 1/2 HP Motor
  • Heavy-duty 600 V 10' SJOOW jacketed lead
  • Stainless Steel Single Shell Housing
  • Compact design while ensuring cool and quiet operation
  • Bottom Suction Design
  • Include 5" removable base for mounting
  • 1-1/4" FNPT Thermoplastic Discharge Head
  • Resists breakage during installation
  • Molded Hydraulic Components
  • Optimized for increased performance and decreased power usage
  • 12-Month Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

90301005
specs product image PID-153018
General Information
Product Category
Water Pump
Motor
Voltage
120 Volt
Running Amps
9
Wire
2-Wire
Power Cord Length
10 Feet
Pump
Gallons Per Minute
10 Gallons
Outlet Diameter
1-1/4 Inch
Housing Material
Stainless Steel
Impeller Material
Plastic
Handles Solids
Yes
Maximum PSI
93
Max Head
225 Feet
Submersible
Yes
Engine
Horsepower
0.5 HP
Overview
Product Category
Water Pump
Weight
16 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
26 Inches
Product Width
5 Inches
UPC
029753000051
