Features
Grade
Contractor
Style
Portable - Horizontal
CFM
18.5
Tank Size
25
- Rugged 5-HP Running HP Electric Air Compressor
- Heavy duty design elements for top performance
- Cast Iron Pump And Premium Air Filters
- Long lasting and easy to maintain
- "V" Design minimizes vibration, improves cooling & extends compressor life
- Individual & Removable Cylinders
- For smoother and cooler operation
- 25 Gallon Air Tank With Liquid Filled Pressure Gauge
- Rated to 170 PSI; 18.5 CFM @ 100 PSI runs powerful tools
- Sturdy Pneumatic Tires
- Easy handling & maneuverability
- Efficient Heat Removal From Pulley-Fan
- For cooler running and longer life
- Sturdy Metal Belt Guard
- Protects you and the belt during operation & transport
- Outlet Valve & Regulator Included
- Easy view oil sight glass makes maintenance simple
- Generous 2 Year Factory Warranty
- Protects your investment
**Due To Product Issue Unit Will Be Built On A Black Tank Until Further Notice**
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
P5125H1-MAP
Engine
HP
5
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
18.5
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
170 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
25 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
250 Pounds
Certification
CSA/US
Consumer Warranty
2 Years
Product Length
44 Inches
Product Width
18 Inches
Product Height
33 Inches
Power Type
Electric
UPC
020791502095
Reviews
(3)
MAXair P5125H1-MAP Reviews & Ratings
Product Q&A
Be the First to Ask A Question
Answered by Melissa, the Air Compressor Expert
How-To Articles
How To Pick The Perfect Contractor Air Compressor
From the ground up, construction relies on compressed air. From framing a home ...
Air Compressor Maintenance Checklist
Air compressors are a major investment, and keeping yours running in top condit...
How to Pick the Perfect Portable Single-Stage Compressor
We've all heard that Rome wasn't built in a day, but then again the R...
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
MAXair 5-HP 25-Gallon (Belt-Drive) Cast-Iron Air Compressor
