MEGA 5-HP 80-Gallon Two-Stage Air Compressor (208V/230V 1-Phase - 175 PSI)
Model:
MP-6580V2
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
7
Model: 21999-0177
$109.80
In-Stock
$66.99
In-Stock
Model: TRI-GD-1100P-GL
$65.00
Factory-Direct
Model: TRI-GD-2100P-GL
$95.00
Factory-Direct
Model: DXCM024-0400
$209.00
Factory-Direct
Model: IDU11E-10-K
$2,199.00
Factory-Direct
Model: 21999-0415
$406.80
Features
Grade
Contractor
Voltage
208-230 Volt AC
Phase
1-Phase
CFM
18.5
Tank Size
80
- MEGA Two-Stage Air Compressor
- Perfect for DIY projects to the professional air compressor user
- Heavy-Duty 5-HP Induction Motor
- 208/230-volt single-phase motor runs at 3450 RPM
- Provides maximum performance and efficiency
- Delivers 18.5 CFM @ 90 PSI; 14 CFM @ 175 PSI (Max)
- Plenty of power to run a wide range of air tools
- Tackle airbrushing, drilling, sanding and bolting/wrenching
- Cast Iron V-Twin Oil Lubricated Pump
- Thermally stable cast iron cylinder body
- Aluminum head and machine cast iron valve plate
- Aluminum pump head helps dissipate heat for longer pump life
- "W" Design
- Minimizes vibration, improves cooling, extends compressor life
- One-Piece Cast Iron Crankcase
- Durable automotive-style ball bearings
- Stainless steel reed valves for increased volumetric efficiency
- 80-Gallon Vertical Tank
- Fully enclosed belt guard protects you and the belt
- Easy-access manual drain simplifies routine maintenance
- Easy Viewing Oil Sight Glass On Pump
- Easily check compressors pump oil level
- Conveniently accessible oil fill for fast maintenance
- 1-Year Limited Manufacturer Warranty
- Protect your investment
- Shipped with 100% full synthetic air compressor oil
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
MP-6580V2
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
21
Recommended Breaker
30 Amp Breaker
Engine
HP
5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
18.5
CFM Rated @
90 PSI
Pump Material
Cast Iron w/ Aluminum Head
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
80 Gallons
Tank Included
Yes
Tank Outlet
3/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
508 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
34 Inches
Product Width
32 Inches
Product Height
74 Inches
Power Type
Electric
UPC
376204971393
Reviews
(15)
MEGA Compressor MP-6580V2 Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.87
(15 Ratings)
5
(14)
(14)4(0)
(0)3(1)
(1)2(0)
(0)1(0)
(0)
Excellent Value
By Jason H.
Utah
Purchased 02/20/2025 |
Review Posted 03/25/2025
Excellent value on this large compressor.
Jason H. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
MEGA 80 Gal. 5-HP MP-6580V2 Air Compressor
By Steve B.
Michigan
Purchased 02/27/2025 |
Review Posted 03/13/2025
I just received this Air Compressor (Mega MP-6580V2) and it has exceeded my expectations. From my initial discussions with Air Compressor Direct and the delivery, the process was flawless. The unit is a beast and hopefully will last as long as my 60 gallon Puma, which is 39 years old and still functioning.
This compressor is fairly quiet and pumps up fast.....Highly recommend!
This compressor is fairly quiet and pumps up fast.....Highly recommend!
Steve B. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
I39d Buy It Again
Cons:
None
MEGA 5-HP 80-Gallon Two-Stage Air Compressor
By Greg J.
New Jersey
Purchased 12/31/2024 |
Review Posted 02/17/2025
My overall experience with buying this product through Air Compressors Direct was excellent from ordering to shipping and receiving. I had no issues hooking the unit up, once it was running, I was extremely happy with how quiet it was and how quickly it reached its pressure shut-off. I agree with everyone else, the on/off switch feels week, other than that, 5 stars!!!
Greg J. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
Good Air Compressor
By Chaz P.
Alabama
Purchased 12/02/2024 |
Review Posted 02/13/2025
Best deal for a 80 gallon compressor I could find. Way quieter than anticipated. Only complaint is the drain on the bottom of the tank is not the easiest thing to get to or to open. I plan on swapping the drain with a valve. Overall extremely happy with product so far.
Chaz P. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
Heavy
Mega Compressor
By Mark
North Carolina
Purchased 11/20/2024 |
Review Posted 12/17/2024
Great bang for the buck got it on sale the best price I could find with 80 gallon tank at 175psi and 18cfm at 90psi that’s a ton of air for the price point even better then others in the $2000 price range shipping was a easy wiring was simple and no problems on first start up was much quieter then I expected and assembled in the USA hopefully last a long time but so far very happy with purchase.
Mark Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
MEGA Compressor Model: MP-6580V2
By Joshua
Pennsylvania
Purchased 08/30/2024 |
Review Posted 12/11/2024
Over all a great compressor for a good price, holds pressure well, and its pretty quiet considering i have it in an open 2 car garage.
Joshua Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price
Cons:
None
Great Compressor For The Pice
By Joe K.
Pennsylvania
Purchased 10/27/2024 |
Review Posted 11/23/2024
Shipped very quick. Arrived with minor damage to one of the air cleaner housings. Contacted customer service. They had the new part to me in no time. Real easy to hook up, surprised how quiet this unit is.
Joe K. Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
4/5
5/5
Pros:
Price, High Quality, Exceeded Expectations, Quiet
Cons:
None
Easy To Use, Great Quality
By Greg R.
Texas
Purchased 10/30/2024 |
Review Posted 11/08/2024
Sturdy build, all components are excellent quality, keeps up with my spray gun very well and eliminated splattering I was having with my old compressor.
Greg R. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Pros:
Easy To Use, High Quality, Reliable, Durable
Cons:
Heavy
Last One I Will Buy
By Big Jeff
Oklahoma
Purchased 08/25/2024 |
Review Posted 09/07/2024
Did my research and needed this 80 gallon for my shop to run multiple outlets. I will be running plasma cutters, sanders, and impacts. So I picked this one even though it didn't have a lot of reviews but the ones I read were good. Bought and 10 days received my compressor. Installed in the shop and started up and shut off at 175 psi. Ran a few impacts and plasma cutter at the time of install and all went perfect. This will be my last air compressor.
Big Jeff Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Good Compressor So Far
By Chris
Illinois
Review Posted 08/12/2024
Needed something with 208v that could keep up with a box folding machine and this fit the bill. Not too loud and so far is working great. No complaints.
Chris Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
