Mercury 15 HP (15") Shaft EFI Outboard Motor

Model:

1A15201LK

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Mercury 15 HP (15
Mercury 15 HP (15") Shaft EFI Outboard Motor
Model: 1A15201LK
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Highly Efficient EFI (Electronic Fuel Injection) Engine
  • Large displacement (SOHC) & maintenance-free valve train
  • Battery-free EFI reduces weight for easier portability
  • Easy starting, burns less fuel and requires less maintenance vs. carburetor system
  • Enhanced Tiller Control
  • Easy to reach and upfront F-N-R shift lever
  • Reversible throttle grip rotation for right or left-hand operation
  • Vertical height is adjustable for operator's reach and preference
  • Built-To-Last
  • Durable 2.15:1 gear ratio for added thrust in any direction
  • Dual water intake ensures proper water cooling
  • Overheating, low oil pressure and over-rev protection alerts keep you and your engine safe
  • Six Trim Positions w/ Shallow Drive
  • Shallow Drive System tilts the motor for operation in shallow waters
  • Two-stage rubber mount system significantly reduces engine vibration
  • Maintenance Schedule Decal
  • On air silencer provides quick overview of routine maintenance
  • Includes what to check and inspect at 100 and 300-hour intervals
  • Also, includes key specifications and model information
  • Key Maintenance Features
  • Features an easy access in-line water separating fuel filter
  • Convenient freshwater flushing attachment
  • Quick and easy no-mess oil and filter change
  • The motor is NOT capable of remote operation, tiller handle control use ONLY
  • ***State Registrations Take 2-3 Weeks To Arrive After Request***
California residents see
Warning: This product can expose you to chemicals including Gasoline engine exhaust (condensates/extracts) which is known to the State of California to cause Cancer
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

1A15201LK
specs product image PID-97585
General Information
Product Category
Outboard Motor
Engine
CARB Compliant
Yes
Fuel System
EFI
Engine Brand
Mercury
Engine Type
4-Stroke SOHC
Cylinder Count
2 Cylinder
Horsepower
15
Engine Displacement
333 CCs
Bore & Stroke
2.40 x 2.24 Inches
Full Throttle RPM Range
5,700 - 6,200
Starting System
Recoil
Cooling System
Water Cooled
Ignition System
Digital CDI
Exhaust System
Through Prop
Power Tilt
No
External Fuel Tank
Included w/ Fuel Hose
Power Trim
No
Fuel
Unleaded 87 Octane
Fuel Tank Capacity
3.2 US gal Aux Tank
Oil Recommended Viscosity
10W-30 Marine Oil
Oil Pressure Alert
Yes
Engine Oil Capacity
1.1 US qt. (35.2 oz.)
Engine Oil Included
No
Drive
Steering
Tiller
Gear Ratio
2.15:1
Gear Shift
F-N-R
Propeller Blades
3
Propeller Material
Aluminum
Transom Height
15 Inches
Overview
Product Category
Outboard Motor
Weight
105 Pounds
Consumer Warranty
3 Years
Product Length
51 Inches
Product Width
13 Inches
Product Height
34 Inches
Power Type
Gas
UPC
678633127281
Additional Model Numbers

1A15201BK, 1A15201LK
