Features
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- Powerfully Compact
- 123cc displacement single cylinder provides optimal power output
- Overhead valve design with hardened valve seats for added durability
- Light and portable, starting at just 59.5 lbs.
- Clean Burning Propane
- A reliable fuel- does not degrade, require additives, or contain ethanol
- Easy, primer-free ignition with no carburetor to worry about maintaining
- Hours Of Boating Fun
- 5 hours running time @ 5000 rpm with 20 lb. standard propane tank
- The same conventional propane tanks used on grills and heaters
- Automatically shuts off propane gas flow when the engine stops
- Unrestricted Control
- Easy to reach forward mounted F-N-R shift lever
- Twist grip throttle for easy access and precise throttle control
- Co-pilot friction adjusters for fine-tuning throttle and steering resistance
- Easy Starting
- Designed with capacitor discharge (CD) ignition for a quicker charge
- Built-in decompression combined with a hotter spark makes pull starts a breeze
- Six Manual Trim Positions
- Exercise 1 of 6 tilt positions for maximum control and performance
- Tilt Lock System locks motor in place when removing from water or portaging
- Exclusive Through-Prop Exhaust
- Exhaust is emitted through the prop for significant noise reduction
- Designed with a shear pin for added drive protection
- Aluminum with rubber hub propeller instead of plastic (less slippage)
- Easy Maintenance & Transportation
- Lightweight design and built-in handles for painless transportation
- Features an oil drain plug for quick and hassle-free oil changes
- The motor is NOT capable of remote operation, tiller handle control use ONLY
- ***State Registrations Take 2-3 Weeks To Arrive After Request***
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
1FP5201EK
General Information
Product Category
Outboard Motor
Engine
CARB Compliant
Yes
Fuel System
Propane Mixer
Engine Brand
Mercury
Engine Type
4-Stroke OHV
Cylinder Count
1 Cylinder
Horsepower
5
Engine Displacement
123 CCs
Bore & Stroke
2.32 x 1.77 Inches
Full Throttle RPM Range
5,000 - 6,000
Starting System
Recoil
Cooling System
Water Cooled
Ignition System
Digital CDI
Exhaust System
Through Prop
Power Tilt
No
External Fuel Tank
No
Power Trim
No
Fuel
HD-5 (65% Propane or Greater)
Oil Recommended Viscosity
10W-30 Marine Oil
Oil Pressure Alert
Yes
Engine Oil Capacity
.47 US qt. (15 oz.)
Engine Oil Included
No
Drive
Steering
Tiller
Gear Ratio
2.15:1
Gear Shift
F-N-R
Propeller Blades
3
Propeller Material
Aluminum
Transom Height
15 Inches
Overview
Product Category
Outboard Motor
Weight
59 Pounds
Consumer Warranty
3 Years
Product Length
41 Inches
Product Width
13 Inches
Product Height
21 Inches
Power Type
Propane
UPC
678633103575
Reviews
(3)
Mercury Marine 1FP5201EK Reviews & Ratings
How-To Articles
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Mercury 5 HP (15") Shaft Propane Powered Outboard Motor
