Features
Grade
Commercial
Voltage
208-230 Volt AC
Phase
1-Phase
CFM
17
Tank Size
80
- 208-230 Volt, Single Phase 6.5HP Induction Motor
- Reliable power for craftspeople & light commercial use
- Magnetic starter prevents motor overloads
- 2 Stage Cast-Iron 900 RPM Pump
- Produces 17 CFM at 90 PSI, 16 CFM at 175 PSI
- Oil Lubricated
- Runs quietly & reliably
- 80 Gallon Vertical Tank
- ASME & CRN certified for reliability & safety
- 1/2" air outlet; 1/4" drain ball valve; rated to 200 PSI
- Smaller footprint than horizontal models frees up shop space
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
TN-6580VM
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
Yes
Amp Draw
24.5 - 23
Recommended Breaker
Consult Certified Electrician
Engine
HP
6.5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
17
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
500 Pounds
Certification
ASME, CRN
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
32 Inches
Product Height
72 Inches
Power Type
Electric
UPC
636084029042
Reviews
(7)
Puma TN-6580VM Reviews & Ratings
Model TN6580V Compressor
By DfBallou
Oregon
Review Posted 05/13/2023
I bought this about 20 yerars ago, runs great, had no real issues other than last year i put on a new motor & Pressure switch. (2nd switch 1 in 2006..Great Compressor, to bad they have discontinued these.
DfBallou Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
hard to find service info.
Puma Must Hire Unhappy Electricians
By Chris C.
Fayetteville, North Carolina
Purchased 08/01/2020 |
Review Posted 09/16/2020
Other than it was wired backwards by a disgruntled employee on Friday. Once I found an electrician that was able to decipher the magnetic start in conjunction with the on-off switch auto-off deal. It’s an awesome compressor that runs my plasma cutter like a champ. This is my 2nd Puma compressor, 5hp-40gal and the new compressor is 6hp-80gal, I love them both now!
Chris C. Recommends This
Was this review helpful?
Rating Breakdown
4/5
3/5
4/5
4/5
Pros:
Price, Durable, Features, Fast
Cons:
Heavy, Bad Instructions, Wired all wrong
TN-6580VM
By Brian C.
Jefferson, Georgia
Purchased 06/06/2018 |
Review Posted 07/04/2018
Can’t beat it...runs quiet and keeps up with air tools and spray guns all day.
Brian C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Price, Reliable, High Quality
Cons:
None
Stay Away
By Evan B.
Canyon lake, Texas
Purchased 04/25/2018 |
Review Posted 05/29/2018
I ordered this compressor, but they sent the wrong model (5hp). If you’ve already ordered, check the numbers, not just the paperwork. The customer service is lacking and I only got results after going through PED. Now I am getting bills from the shipping service for liftgate service ($120) even though they say no charge for liftgate. The shipping company says someone “typed” it in. They have no problem taking it off, but you have to get someone from PUMA to send a request for that. After waiting almost a month to get this unit and all the trouble, I would say it was my worst online purchase ever. I highly recommend using PED to purchase from anyone, but if you want a PUMA like I did then for sure.
Evan B. Does Not Recommend This
Was this review helpful?
Rating Breakdown
3/5
3/5
1/5
1/5
Pros:
It’s still a good item
Cons:
Hard to deal with customer service.
I Can Finally Get To Paint!
By Evan B.
Canyon Lake, Texas
Purchased 04/25/2018 |
Review Posted 05/25/2018
This is my second PUMA and my old one is still going strong. I got the 6.5 after almost a month, because the first one sent out was not the correct one. That being said I would highly recommend Power Equipment Direct aka Air Compressors Direct. They were easy to work with a very responsive to the issue. This is a well made (USA) product and has some items that are only found on more expensive models. It runs fairly quiet and cool compared to others. If you want to save even more money the 5hp that I received first looked to be a quality product as well and had a substantial 5HP motor. The drivers at FEDEX who picked up and delivered were pros.
Evan B. Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
4/5
4/5
Pros:
Durable, Features, Quiet, Price
Cons:
Heavy
Initial Impression
By Andy P.
Chester, Connecticut
Purchased 11/28/2017 |
Review Posted 01/05/2018
I looked for a good compressor for the better part of a year. And could not decide on a reasonably priced compressor for my needs doing auto restoration work in my garage. I probably read about every compressor on PEDs site. I almost went to a competitor (until I read some reviews) and came back to PED.
I found the Puma 6.5 HP and knew this was the one.
Works as expected and runs all my air tools without a hitch. I was pleasantly surprised that it only required a 30 Amp breaker and # 10 wire. As far as noise, it's not bad, can still hear the radio and talk without screaming.
Delivery was great, the driver brought it right to my garage (my driveway is 1/4 mile long) and helped me jockey it to where I needed it to be.
All in all a great deal and great service.
Thanks PED
I found the Puma 6.5 HP and knew this was the one.
Works as expected and runs all my air tools without a hitch. I was pleasantly surprised that it only required a 30 Amp breaker and # 10 wire. As far as noise, it's not bad, can still hear the radio and talk without screaming.
Delivery was great, the driver brought it right to my garage (my driveway is 1/4 mile long) and helped me jockey it to where I needed it to be.
All in all a great deal and great service.
Thanks PED
Andy P. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
5/5
Pros:
Quiet, Price, I'd Buy It Again
Cons:
Heavy
My compressor
By Charles C.
Chaddsford, Pennsylvania
Purchased 07/05/2016 |
Review Posted 07/28/2016
I bought my compressor from PED. When I received it was damaged,and had a sticker on it identifying that it was damaged. I asked the driver from the trucking company about it.And he didn't know who put the sticker on it or if it was damaged. Trucking company refused to come down my street.I had to drive a forklift down a public street. Then when I get there it is damaged.
Called the trucking company the guy had a personality of a pet rock. So I called the company PED. And talked to a girl named Patty. She apologized about the trucking company and ordered me a new part. It wasn't anything that would affect the compressor from operating. The part came in a couple of days later.
And it looks brand new. PED was excellent to deal with. The trucking company was a nightmare. If I order anything else from PED. I will ask who the delivery is going to be with before I order make my purchase.
Called the trucking company the guy had a personality of a pet rock. So I called the company PED. And talked to a girl named Patty. She apologized about the trucking company and ordered me a new part. It wasn't anything that would affect the compressor from operating. The part came in a couple of days later.
And it looks brand new. PED was excellent to deal with. The trucking company was a nightmare. If I order anything else from PED. I will ask who the delivery is going to be with before I order make my purchase.
Charles C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
How-To Articles
How to Audit Your Compressed Air System
Let's face it, energy isn't cheap and finding ways to cut energy costs is criti...
How to Pick the Perfect Air Compressor
Too much talk about air compressors can get complicated. Let's make itsimple. W...
Power Equipment How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
%20%7C%20Puma%20TN-6580VM&p[url]=https%3A%2F%2Fwww.powerequipmentdirect.com%2FPuma-TN-6580VM-Air-Compressor%2Fp13952.html&p[summary]=Buy%20the%20Puma%20TN-6580VM.%20Sold%20out%20at%20Power%20Equipment%20Direct.%20Also%2C%20read%20the%20latest%20reviews%20for%20the%20Puma%206.5-HP%2080-Gallon%20Two-Stage%20Air%20Compressor%20(208-230V%201-Phase)&p[images][0]=https%3A%2F%2Fwww.powerequipmentdirect.com%2Fproducts-image%2F500%2Ftn-6580vm_13952_1000_f07f0aa48fb48f38e5f9a78fc1ba2d90.png){kind=link}
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Puma 6.5-HP 80-Gallon Two-Stage Air Compressor (208-230V 1-Phase)
