Reliance Controls 104B1
Reliance Controls 104B1
Hover to zoom
1 of 1

Reliance Controls Pro/Tran 2 - 15-Amp (120V 4-Circuit) Indoor Transfer Switch

Model:

104B1

Write A Review
$207.99
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Tuesday, Mar 18th
Shipping to43085
Reliance Controls Pro/Tran 2  - 15-Amp (120V 4-Circuit) Indoor Transfer Switch
Reliance Controls Pro/Tran 2 - 15-Amp (120V 4-Circuit) Indoor Transfer Switch
Model: 104B1
$207.99
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Optional Accessories 5
$76.50
In-Stock
$6.50
In-Stock
$81.99
Only 1 In-Stock
$44.99
In-Stock

Features

Type

Manual

Amp Rating

15

Circuits

4

Voltage

120 Single-Phase

Enclosure

NEMA 1R

  • Pro/Tran® 2 Series 15-Amp 4-Circuit 120V Manual Transfer Swtich
  • Same benefits as the original plus new some new features
  • Safest Way to Distribute Power
  • Eliminates dangerous backfeeds and electrical overloads
  • (4) Total Circuits (1" Interchangable Style)
  • Four 15-Amp Single-Pole (120 Volts) circuits
  • Versatile Connection
  • Allows hardwiring OR plug-in connection via power inlet
  • Enclosure has 6 combination 1/2-inch and 3/4-inch knockouts
  • Hinged, Non-Metalic Cover
  • Protects toggle swtiches/breakrs & povides a finished apperance
  • Simple Connection - Once Switch Is Installed
  • Allows for quick deployment so you'll be up and running fast
  • Safety & Certifications
  • Certified for use by Underwriter Laboratories to UL Stanard 1008
  • Meets all requirements of article 702 of the NEC ANSI/NFPA 70
  • 5-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Cadmium which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-15R (Wall-Type)
104B1
specs product image PID-50912
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
7 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
7.7 Inches
Product Width
7 Inches
Product Height
4.5 Inches
UPC
815181012151
Additional Model Numbers

104B, 104B1

Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Rated Watts
1875 Watts
Rated Amps
15 Amps
Enclosure
NEMA 1R
Conduit Length
18
Number of Circuit Breakers
4
Max Generator Input
15 Amps
Maximum Wattage
1875 Watts
UL Listed
Yes
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA 5-15R - Wall-Type
1

Reviews

(25)
Reliance Controls 104B1 Reviews & Ratings
Customer Rating
4.84
(25 Ratings)
5
(23)
4
(1)
3
(0)
2
(1)
1
(0)
Verified Buyer
Verified Buyer
Does The Job
By Larry
Texas
Purchased 02/17/2024 |
Review Posted 03/11/2024
This product arrived quickly in good condition. Electrician had no problem with installation. Works great with any backup generator and will connect with any regular 3 prong extension cord. Suggest using 14 guage.
Larry Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Price
Cons:
None
Verified Buyer
Verified Buyer
Reliance 104B1
By Mike C
Alabama
Purchased 02/14/2024 |
Review Posted 03/07/2024
A very high quality product, nice design, very user friendly. Simple to install and put into use. This may be less popular as it is only a 15 amp unit. It is a perfect 'fit' for my 2000 watt inverter to power most of my 1100 sq. ft. home. Very glad I chose this one.
Mike C Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use
Cons:
None
Verified Buyer
Verified Buyer
Perfect For Using With Honda EU220 Generator
By Peter H
Oregon
Purchased 12/01/2023 |
Review Posted 12/22/2023
Easy to DIY install. Great instructions. I needed to replace the 3/5 flexible metal conduit with a loner piece, plus I added a wall inlet on outside of house. Great product!
Peter H Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Price, I'd Buy It Again
Verified Buyer
Verified Buyer
Great Item And Great Customer Service!
By Don L
New York
Purchased 02/05/2023 |
Review Posted 02/27/2023
A bit costly, but this is a quality item that is easy to install and does what its supposed to do. My installation allows me to keep a battery power station on standby for essential appliances during a power outage without the noise and hassle of a gas generator. However, should I want to run a combustion type generator in the future, this transfer switch will handle that too!
Don L Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
3/5
icon-review-marker
Pros:
Easy To Use, High Quality, Features, Durable
Cons:
Expensive
Verified Buyer
Verified Buyer
Protran
By Tom L
Indiana
Review Posted 02/07/2023
Works great. I had no problems installing it myself. The only issue I had were that printed on markings on the black wires were not readable. I had to sort them out using my ohm meter. Someone apparently recognized the problem as the A wire had a label on it but none of the others did.
Tom L Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Price, I'd Buy It Again
Verified Buyer
Verified Buyer
Reliance 104B Transfer Switch And Installation.
By David D
Florida
Review Posted 01/26/2023
I installed my 104B transfer switch in my 200 Amp. Square D panel. The installation was simple, and the results were excellent. I would recommend this unit to anyone looking to use a small generator to power a few circuits. I run my refrigerator and a few kitchen receptacles. These two circuits were on a double pole breaker because they share the neutral.

The other two circuits power the kitchen lighting and the Master Bedroom and bath. It works flawlessly and was inspected and approved by the local Electrical inspector. Very happy product.
David D Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Price, I'd Buy It Again, Easy To Store
Cons:
None
Verified Buyer
Verified Buyer
As Advertised
By William M
Wisconsin
Review Posted 11/14/2022
The transfer switch arrived in good condition and has performed exactly as advertised. No complaints.
William M Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Price, I'd Buy It Again
Verified Buyer
Verified Buyer
Just What We Were Looking For
By Demers B.
Palmyra, Maine
Purchased 04/17/2021 |
Review Posted 08/09/2021
We have the Honda 2200 generator and the 4 circuits was all that we needed.
Demers B. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, High Quality, Price, Id Buy It Again
Verified Buyer
Verified Buyer
Great Price On Quality Equipment
By Brian D.
Palmyra, Maine
Purchased 04/17/2021 |
Review Posted 06/23/2021
This will work great for my backup generator.
Brian D. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, High Quality, Price, Id Buy It Again
Verified Buyer
Verified Buyer
Works
By Sam S.
Spring Hill, Florida
Purchased 03/29/2021 |
Review Posted 06/23/2021
Had this installed by an electrician and tested ok.. Quality seems first class. Have not had the need to use it so far. Will see what the hurricane season brings
Sam S. Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
4/5
icon-review-marker
Value
4/5
icon-review-marker
Pros:
Easy To Use, High Quality, Id Buy It Again, Features
