Reliance Controls Pro/Tran2 - 30-Amp (120/240V 10-Circuit) Outdoor Transfer Switch w/ Wattmeters & Inlet
Model:
R310A
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Jared, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Type
Manual
Amp Rating
30
Circuits
10
Voltage
120/240 Single-Phase
Enclosure
NEMA 3R
- Pro/Tran® 2 30A 10-Circuit 120/240V Outdoor Manual Transfer Switch
- The next generation of Loadside™ manual transfer switches
- Non-Defeatable (Break-Before-Make) Double-Throw Switch
- Eliminates dangerous backfeeds and electrical overloads
- 10 Total Circuits (1" Interchangable Style)
- (6) 15A 1-Pole, (2) 20A 1-Pole, (1) 20A 2-Pole; Easily re-configured in the field
- NEW Color-Coded Built-In Analog Wattmeters
- Helps you balance and manage generator load
- Factory Installed 30-Amp (L14-30) Power Inlet w/ Flip-Lid
- Easily connect your generator cord on bottom of switch
- NEMA 3R Powder-Coated Steel Cabinet For Outdoor Installation
- Gasketed design, provides liquid tight protection in all seasons
- Key lockable door prevents tampering & unauthorized use
- 16" Flexible, Non-Metalic Liquid-Tight Conduit (1") w/ Fittings
- (5) Combination 1/2" & 3/4" knockouts for easier installation
- Factory-marked, color-coded wires simplifies installation
- Safety & Certifications
- Certified for use by Underwriter Laboratories to UL Stanard 1008
- Meets all requirements of article 702 of the NEC ANSI/NFPA 70
- 5-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Cadmium which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
R310A
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
25 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
13 Inches
Product Width
12 Inches
Product Height
5 Inches
UPC
815181012793
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
7500 Watts
Rated Amps
30 Amps
Enclosure
NEMA 3R
Conduit Length
16
Number of Circuit Breakers
10
Max Generator Input
30 Amps
Maximum Wattage
7500 Watts
UL Listed
Yes
Transfer Switch Circuits
15A 120V
6
20A 120V
2
20A 240V
1
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-30R
1
