Reznor UDAP-200 Power Vented Gas Fired Unit Heater, NG, Aluminized Heat Exchanger - 200,000 BTU

Model:

UDAP-200

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Reznor UDAP-200 Power Vented Gas Fired Unit Heater, NG, Aluminized Heat Exchanger - 200,000 BTU
Reznor UDAP-200 Power Vented Gas Fired Unit Heater, NG, Aluminized Heat Exchanger - 200,000 BTU
Model: UDAP-200
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Reznor UDAP-200 Gas Fired Unit Heater is a 115 volt, gas fired unit heater designed to provide efficient heating. Reznor UDAP-200 uses a single burner combustion system to provide a 166,000 BTU/hr. output with an 82-83% thermal efficiency. UDAP-200 provides a 50-60 F rise range. UDAP models use an integrated circuit board with diagnostic indicator lights to control heater operation. External gas connection allows for easy gas service connection. Reznor UDAP-200 can be suspended from either 2 or 4 suspension points or ceiling mounted with an optional hanger kit. UDAP-200 provides improved efficiency and easier installation over previous Reznor models.
  • Reznor UDAP-200 Features
  • Commercial/industrial certification
  • Multi-try direct spark ignition with 100% lockout
  • Vibration isolated fan and venter motors
  • 2-pt and 4-pt suspension points
  • External gas connection
  • Product Note
    The image may not reflect actual product features. The Reznor UDAP-200 comes with five horizontal louvers.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

UDAP-200
specs product image PID-46940
General Information
Product Line
UDAP
Heat Exchanger Material
Aluminized Steel
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Power Vent
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal
Mount Type
Suspended
UPC
673905465948
Performance
Heating Capacity
166000 BTU
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
200000 BTU
Thermal Efficiency
83 %
Maximum Air Flow
2562 CFM
Minimum Air Flow
2562 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Primary Vent Pipe Diameter
5 Inches
Flue Connection Size
5 Inches
Gas Connection Size
1/2 Inch
Gas Piping Diameter
1/2 Inch
Product Height
20 1/8 Inches
Product Width
38 Inches
Product Depth
42 Inches
Product Weight
187 Pounds
Shipping Weight
219 Pounds
Certifications
Country of Origin
United States
CSA Listed
Yes
ANSI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
