Schulz V-Series 7.5-HP 80-Gallon Two-Stage Air Compressor (230V 1-Phase)
Model:
932.9341-0
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
7
Model: 21999-0177
$109.80
In-Stock
$66.99
In-Stock
$288.00
Only 5 In-Stock
Model: SMH40-UP
$1,831.00
Only 4 In-Stock
$150.62
Factory-Direct
Model: DXCM024-0344
$200.99
Factory-Direct
Model: 018-0060CT
$14.00
Factory-Direct
Features
Grade
Commercial
Voltage
230 Volt AC
Phase
1-Phase
CFM
20.1
Tank Size
80
- WEG Electric Motor
- 7.5 HP motor reliably handles commercial duty demands
- V-Series Cast Iron Pump
- Runs cooler, lasts longer due to the space between each cylinder
- Deeper cylinder fins for additional heat dissipation
- Oversized Main Bearings
- Sturdy & reliable
- Swedish Steel Valves
- Quality components contribute to pump efficiency
- CNC Machined Components
- Accurate fit produces top-notch performance
- Notched Belts Standard
- Enclosed belt guard protects the belt & operators
- Powder Coated Components
- Resist rust & corrosion
- 1 Year Unit With 2 Year Pump Warranty
- Protects your investment
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
932.9341-0
General Information
Product Category
Air Compressor - Stationary
Engine
HP
7.5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
20.1
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Overview
Product Category
Air Compressor - Stationary
Weight
728 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
48 Inches
Product Width
42 Inches
Product Height
81 Inches
Power Type
Electric
Additional Model Numbers
7580VV30X-1, 932.9341-0
Reviews
(7)
Schulz 932.9341-0 Reviews & Ratings
Manufacturer Review
Buy once. Buy for life.
By Andre Kellner
Schulz Products Manager
Review Posted 10/10/2014
Our most popular model. The 7.5HP 80 Gallon SCHULZ Heavy Duty compressor is built to the highest standards of quality. The Cast Iron pump is manufactured using our own foundry which is located right next to our ASME & ISO certified compressor factory. We use high quality WEG electric motors in all of our units, as well as WEG electrical components in the Magnetic Starter with Thermal Overload protector to ensure your compressor will resist any surges in the electrical network.
This compressor is perfect for a mechanic’s shop, home auto enthusiast and fabricators, or anywhere else that you need quiet, dependable, compressed air at a very affordable price with unbeatable quality. Pair this compressor with one of our refrigerated air dryers and enjoy years of long lasting service. The 80 Gallon tank ensures that you have enough air to power all of your air tools while keeping compressor run times very low.
Don’t waste your money on products made with inferior materials and aluminum pumps which will give out right as the warranty expires. Buy a Schulz cast-iron compressor and have peace-of-mind for years of reliable service with easy maintenance.
This compressor is perfect for a mechanic’s shop, home auto enthusiast and fabricators, or anywhere else that you need quiet, dependable, compressed air at a very affordable price with unbeatable quality. Pair this compressor with one of our refrigerated air dryers and enjoy years of long lasting service. The 80 Gallon tank ensures that you have enough air to power all of your air tools while keeping compressor run times very low.
Don’t waste your money on products made with inferior materials and aluminum pumps which will give out right as the warranty expires. Buy a Schulz cast-iron compressor and have peace-of-mind for years of reliable service with easy maintenance.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Solid Air
By Paul W.
Florida
Purchased 12/05/2023 |
Review Posted 01/18/2024
High CFM along with a simple dryer and you get a very low maintenance compressor that just makes air all day long. This is my 5th one in 20 years I use 2 in tandem and have run a mid sized granite shop. In my opinion best bang for the buck hands down.
Paul W. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
Great Purchase
By Fred P
Kentucky
Purchased 12/23/2022 |
Review Posted 03/26/2023
Looked at all brands out there and this appeared to be the strongest and it didn't disappoint. Excellent quality, only time of course will tell but right now I am very satisfied with my purchase.
Fred P Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again
Cons:
None
Quiet And Strong
By Matt C
Georgia
Review Posted 01/31/2023
Quiet and strong.
Matt C Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again
Cons:
None
Compressor
By Josh
Illinois
Review Posted 08/16/2022
Best air compressor I've ever had, also love the fact that it's made in the USA. The thing is a beast when it comes to using the air tools I have for working on the cars.
Josh Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again
Cons:
Heavy
Exceeds Expectations
By Kay T.
Florence, South Carolina
Purchased 10/15/2015 |
Review Posted 12/08/2015
Our company specializes in diesel heavy-duty vehicles. This compressor gives us the pressure we need to perform all tasks.
We are very satisfied with this product.
We are very satisfied with this product.
Kay T. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Very nice
By Mark
Nevada
Purchased 04/24/2014 |
Review Posted 09/14/2014
I am very pleased with the unit, though I by far under-utilize it. The quality is very high, and this is a heavy, well designed unit. Shipping was very fast, and technical support is excellent. The only problem was that the recommended breaker size was not in the documentation, but a phone call to Schulz took care of that. I would definitely buy again.
Mark Recommends This
Was this review helpful?
Manufacturer Response
Thanks for the review! We are very glad you are enjoying your new compressor. We take pride in getting our compressors shipped very quickly and keeping our customers happy even after the sale! Please don't hesitate to contact us again. Enjoy!!
Rating Breakdown
4/5
5/5
5/5
5/5
Pros:
Quiet, Price, High Quality, I'd Buy It Again
Cons:
Heavy
Product Q&A
(1)
Product Questions
Answered by Melissa, the Air Compressor Expert
How loud is it during operation?
Paul
from Delaware
August 22, 2023
