Features
Inlet Size
2 Inch
Style
Diaphragm
GPM
32 Gallons
- Tsurumi Pump 2" Electric Diaphragm Pump
- Ideal for muddy, slurry and thick liquids (high solid content)
- Handles solids up to 1-1/4" diameter & Maximum Temperature 180°F
- 115/230V 1.5 HP Single Phase, AC Motor
- Manual reset overload protects the engine for maximum life
- 2-Stage, Forged Gear Driven Transmission
- Heavy-duty design, operates pump @ 40-strokes per minute
- Sand Cast Aluminum Construction
- Helps reduce weight while still being a very durable pump
- Thermoplastic Santoprene Diaphragm
- Provides extended "wear" life for more pumping and less maintenance
- Built-In Check Valve For Faster Priming
- Helps decrease priming time, once initial prime is created
- Handle & Wheel Kit
- Balanced design makes it easy to transport over uneven terrain
- 90° Rotatable base allows for maximum ease-of-use
- Modular Component Design
- Allows for easier maintenance and cleanout
- Also Includes :
- 2" Steel Suction Strainer & (2) NPT Nipples
- 2-Year Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
TDE6-200
General Information
Product Category
Water Pump
Motor
Voltage
120/240 Volt
Thermal Protection
Yes
Pump
Gallons Per Minute
32 Gallons
Inlet Diameter
2 Inch
Outlet Diameter
2 Inch
Pump Head Material
Aluminum
Housing Material
Aluminum
Solids Handling Size
1.25 inch
Handles Solids
Yes
Suction Head
20 Feet
Total Head Lift
25 Feet
GPH @ 0 feet
1920
GPH @ 5 feet
1620
GPH @ 10 feet
1500
GPH @ 15 feet
1260
GPH @ 20 feet
1140
Check Valve Included
Yes
Submersible
No
Engine
Horsepower
1.5 HP
Overview
Product Category
Water Pump
Weight
165 Pounds
Made in USA
No
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
43.3 Inches
Product Width
20.1 Inches
Product Height
23.2 Inches
Additional Model Numbers
TDE5-200, TDE6-200
Accessories
Strainer
Yes
Lifting Hook
Yes
Wheel Kit
Yes
