Tsurumi TDE6-300 - 59 GPM (3") Electric Diaphragm Pump w/ Wheel Kit

Model:

TDE6-300

Write A Review
$2,439.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-3 Weeks

Tsurumi TDE6-300 - 59 GPM (3
Tsurumi TDE6-300 - 59 GPM (3") Electric Diaphragm Pump w/ Wheel Kit
Model: TDE6-300
$2,439.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

3 Inch

Style

Diaphragm

GPM

59 Gallons

  • Tsurumi 3" Electric Diaphragm Pump
  • Ideal for muddy, slurry and thick liquids (high solid content)
  • Handles solids up to 1-5/8" diameter & Maximum Temperature 180°F
  • 115/230V 1.5 HP Single Phase, AC Motor
  • Manual reset overload protects the engine for maximum life
  • 2-Stage, Forged Gear Driven Transmission
  • Heavy-duty design, operates pump @ 40-strokes per minute
  • Sand Cast Aluminum Construction
  • Helps reduce weight while still being a very durable pump
  • Thermoplastic Santoprene Diaphragm
  • Provides extended "wear" life for more pumping and less maintenance
  • Built-In Check Valve For Faster Priming
  • Helps decrease priming time, once initial prime is created
  • Handle & Wheel Kit
  • Balanced design makes it easy to transport over uneven terrain
  • 90° Rotatable base allows for maximum ease-of-use
  • Modular Component Design
  • Allows for easier maintenance and cleanout
  • Also Includes :
  • 3" Steel Suction Strainer & (2) NPT Nipples
  • 2-Year Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

TDE6-300
specs product image PID-72700
General Information
Product Category
Water Pump
Motor
Voltage
120/240 Volt
Thermal Protection
Yes
Pump
Gallons Per Minute
59 Gallons
Inlet Diameter
3 Inch
Outlet Diameter
3 Inch
Pump Head Material
Aluminum
Housing Material
Aluminum
Solids Handling Size
1.625 inch
Handles Solids
Yes
Suction Head
20 Feet
Total Head Lift
25 Feet
GPH @ 0 feet
3540
GPH @ 5 feet
3360
GPH @ 10 feet
3120
GPH @ 15 feet
2880
GPH @ 20 feet
2460
Discharge Port Size
2 Inch
Check Valve Included
Yes
Submersible
No
Engine
Horsepower
1.5 HP
Overview
Product Category
Water Pump
Weight
185 Pounds
Made in USA
No
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
44.1 Inches
Product Width
26.4 Inches
Product Height
23.4 Inches
Additional Model Numbers

TDE5-300, TDE6-300

Accessories
Strainer
Yes
Lifting Hook
Yes
Wheel Kit
Yes
