Features
Style
Refrigerated
Dryer Voltage
115V 1-Phase
Air Dryer CFM
25
- ABAC COOL25 Refrigerated Air Dryer
- Handles up to 25 CFM at 232 PSI maximum
- Extremely quiet operation and 1/2" fittings for easy connection
- Commonly used for pneumatic applications & general industry
- Simple, Low Maintenance Technology
- Efficiently removes water pollution from your network
- Compact design saves space and easy access for quick servicing
- Large Heat Exchangers
- Low load losses and high thermal exchange cool effectively
- Integrated water separator allows highly efficient water-air separation
- Refrigerant filter for added protection against possible dirty particles
- Low Pressure Drop Design
- Larger flow circuits significantly increase high exchange efficiency
- Hot gas by-pass valve maintains constant pressure in evaporator
- Dew Point Indicator
- Pressure dewpoint of 50°F
- Check air flow status at a glance
- Environmentally Friendly
- Uses R134a refrigerant that's easy on the environment
- Allows lower Global Warming Potential (GWP)
- Avoid corrosion, leakage and rust in pipes & tools for longer lifespan
- Extremely Fast & Easy To Install
- Works with most compressor technology
- Runs on standard 115-volt, single-phase power
- Zero Loss Automatic Drain
- Dumps the accumulated water without wasting air
- Simplifies maintenance, saves energy dollars & higher final product quality
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
AB-COOL25
General Information
Product Category
Air Compressor Accessories
Air Dryer
Dryer Voltage
115V 1-Phase
Air Dryer CFM
Air Dryer CFM
All compressed air dryers have a maximum drying capacity expressed in Cubic Feet Per Minute (CFM)
25
Max PSI
Max PSI
The most amount of PSI that be passed through a dryer
232
Max Inlet Temp. Rating
Max Inlet Temp. Rating
The highest temperature the compressed air can be passing through the dryer for the dryer to operate properly and effectively
122
Max Ambient Temp. Rating
Max Ambient Temp. Rating
Ambient temperature is the air temperature of any object or environment where equipment is stored
104
Non-Cycling
Non-Cycling
Non-cycling refrigerated air dryers have refrigeration compressors that start as soon as you turn the dryer on ― and don't stop until you turn the dryer off. They are less expensive than cycling dryers and are a good choice for applications where they will constantly run at full capacity
Yes
Inlet Fittings
1/2"
Outlet Fittings
1/2"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
No
Auto Drain
Auto Drain
Auto drain or drip leg drain used to drain air line of condensate and water
Yes
Regenerative
No
High Temp
High Temp
Dryers that are specifically designed to handle higher inlet temperatures than regular dryers. Typically paired with a piston or reciprocating air compressor
No
Overview
Product Category
Air Compressor Accessories
Weight
42 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
9 Inches
Product Width
22 Inches
Product Height
22 Inches
Power Type
Electric
Additional Model Numbers
4102006313, AB-COOL25
Reviews
ABAC AB-COOL25 Reviews & Ratings
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Please share your insights with fellow shoppers.
Product Q&A
Be the First to Ask A Question
Answered by Melissa, the Air Compressor Expert
How-To Articles
How to Pick the Perfect Compressed Air Dryer
Ever heard the saying an ounce of prevention is worth a pound of cure? Well, if...
What an Air Line Filter is and How it Works
Without an air line filter - water, oil, and dirt can cause major damage to pne...
How to Pick the Perfect Refrigerated Air Compressor Dryer
Refrigerated Dryers use a cooling system similar to that of a home air conditio...
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
ABAC COOL25 1/2" Non-Cycling Refrigerated Air Dryer (25 CFM)
