California Air Tools IP Light & Quiet .6-HP 1-Gallon Steel Tank Hot Dog Air Compressor
Model:
CAT-1P1060S
+
Share This Product
Similar Products
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
10
$19.00
In-Stock
Model: CAT-AUX05A
$113.00
Factory-Direct
Model: PL155800AV
$50.00
Factory-Direct
Model: DXCM024-0344
$200.99
Factory-Direct
Model: DXCM024-0343
$170.99
Factory-Direct
Model: DXCM012-0200
$30.99
Factory-Direct
Model: IH-AFN34
$216.00
Factory-Direct
Model: 018-0059CT
$4.99
Factory-Direct
Model: HYP380502-O
$27.99
Factory-Direct
$84.97
Factory-Direct
Features
Grade
Consumer
Style
Hot Dog
CFM
1.2
Tank Size
1
California Air Tools IP Light & Quiet .6-HP 1-Gallon Steel Tank Hot Dog Air Compressor
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- "IP" Ultra Quiet Air Compressor & Oil-Free Motor
- One of the quietest air compressors in the industry at 56dBA
- Ideal for anyone working inside where noise is a major issue
- High Performance Oil-Free Pump
- Engineered for high performance and durability
- Easy to use in a variety of different temperatures & uneven terrains
- Produces 1.2 CFM At 90 PSI
- Recovery time from 90 PSI to 120 PSI - 15 Seconds
- Tank fill rate from empty to full - 50 Seconds
- Perfect for staple nail guns, airbrushes, inflating tires and much more
- Oil-Free .6 HP rated/running, 1.2 HP Peak Motor
- Operates at only 1680 RPM creating less noise and less wear
- Large single-piston engineered for high performance and durability
- Reliable & Durable
- Thermal overload protector for maximum protection
- 3000+ hour life cycle before wear; comparable units are 250 hours or less
- 1-Gallon Steel Air Tank
- Light weight at 29.5 pounds so it's easy to transport
- Easy access tank drain simplifies maintenance; rubber feet reduce vibration
- Roll Bar Handle
- Protects unit without getting in the way; keeps unit balanced while you carry it
- Convenient Controls
- Pressure regulator is large and easy to access
- Dual gauges let you monitor tank and tool pressure at a glance
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
CAT-1P1060S
General Information
Product Category
Air Compressor - Portable
Motor
Voltage
110 Volt AC
Phase
1-Phase
dBA
dBA
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
56
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
4.5
Engine
HP
.6
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
1.2
CFM Rated @
90 PSI
CFM @ 40 PSI
1.6
Pump Material
Aluminum
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
120 PSI
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Direct Drive
Oil Type
Oil Free
Tank
Tank Size
1 Gallon
Tank Outlet
1/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Product Category
Air Compressor - Portable
Weight
29.5 Pounds
Certification
ETL
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
12.6 Inches
Product Width
15.1 Inches
Product Height
15 Inches
Power Type
Electric
UPC
743369710608
Reviews
(48)
California Air Tools CAT-1P1060S Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.83
(48 Ratings)
5
(43)
(43)4(3)
(3)3(1)
(1)2(1)
(1)1(0)
(0)
Wanted To Like It So Badly
By Ryan W.
Colorado
Purchased 10/01/2024 |
Review Posted 11/12/2024
It's such a nice air compressor in several ways. You can tell it was quality built, and it's def super quiet. However, my primary needs were basic garage uses like airing vehicle tires and using an air hose to clean filters, and unfortunately it is just way too small for those purposes. With an air hose, you will get about 3 seconds of pressure until the tank is empty, no exaggeration. Takes 60 seconds to fill back up, so you're waiting for over 5 minutes to get 12-15 seconds of air pressure from this thing. Made a quick and easy job take much longer than it should have and I can't see any reasonable person actually being able to use this thing effectively or efficiently, making the air compressor, sadly, useless in many ways.
I'd imagine it'd be great for a nail gun, but if you need an air hose don't waste your money b/c you'll just have to upgrade to a larger compressor. Such a shame that all that craftsmanship is of no practical use.
Maybe it'll sell at a yard sale next summer....
I'd imagine it'd be great for a nail gun, but if you need an air hose don't waste your money b/c you'll just have to upgrade to a larger compressor. Such a shame that all that craftsmanship is of no practical use.
Maybe it'll sell at a yard sale next summer....
Ryan W. Does Not Recommend This
Was this review helpful?
Rating Breakdown
4/5
5/5
1/5
1/5
Pros:
Easy To Store, Quiet
Cons:
Expensive, Far too small
Astonished At The Quietness!
By Nelson V.
Virginia
Purchased 02/06/2024 |
Review Posted 02/29/2024
I needed a quiet compressor for my taxidermy business. I run several airbrushes at once and this little booger is doing very well. One of the biggest reasons I bought it was 1) advertised quietness and 2) small enough to put below my project desk while painting fish and finishing deer heads. Let me just say they are not lying when they say it is one of the quietest compressors on the market. I scored a big win on this one. Much quieter than my Ingersoll and builds back pressure very fast for airbrushing.
From the feel of the compressor to the components attached, everything seems to be robust. I expect to get many years of service out of this unit.
I did add an air filter to this unit to keep my air clean and dry. Other than that, this thing is amazing out of the box for its intended purpose.
From the feel of the compressor to the components attached, everything seems to be robust. I expect to get many years of service out of this unit.
I did add an air filter to this unit to keep my air clean and dry. Other than that, this thing is amazing out of the box for its intended purpose.
Nelson V. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Cons:
None
Should Have Bought This Year's Ago
By Stewart I
California
Purchased 10/15/2023 |
Review Posted 11/06/2023
I always wanted a compressor, but didn't want the noise. This one is a dream! I use it for low volume use with a brad nail gun and filling car tires and almost don't even notice when the compressor turns on, it's super quiet, light, so even with a small tank, it just works.
Stewart I Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again, Easy To Store
Cons:
None
Fun To Use!!!!
By Robert G
Maryland
Review Posted 02/07/2023
This little guy is great to bring right in the house. I’m finishing up a bath build now and use this semi silent compressor to run the finish nailers and for clean up. Just the ticket for working in tight spaces.
Robert G Recommends This
Was this review helpful?
Rating Breakdown
5/5
4/5
4/5
3/5
Pros:
Easy To Use, Price, Quiet, Light Weight
Works Very Well And Pretty Quiet Too
By Kelly F
Washington
Review Posted 01/10/2023
So I have had this little air compressor for a couple of weeks now and have already used it for about 15 hours or so and no issues at all. Everything works just as it should. On my application only because I use it for 30 min at a time before it shuts off to cool down for a few minutes. I added a Noctua 120mm Industrial PPC fan which fits perfect to the front just to keep it running even cooler. I am not recommending anybody add a fan. I added a fan only because my compressor is activated by an automated system and the fan I added keeps it running about 80 degrees cooler. The box says it can be run for 30 to 60 min depending on the psi needed. And it has a thermal overload switch.
Kelly F Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, I'd Buy It Again, Reliable, Quiet
Cons:
None
Perfect For Light Duty At Home Shop
By Peter L.
Pennsylvania
Review Posted 09/17/2022
A nice, well-built unit, that works flawlessly out of the box. Instruction manual could be better, but there's not a lot to it, and they did the job. I love how quiet this compressor is, and it's easy to schlep around. Build quality seems excellent.
Peter L. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, I'd Buy It Again, Easy To Store
Cons:
None
Works Well
By Dexterony
Connecticut
Review Posted 07/07/2022
Does the job as advertised.
Dexterony Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again, Easy To Store
Cons:
None
Meets My Needs
By John N
Michigan
Review Posted 06/14/2022
I wanted a air compressor for my basement so being quiet and high quality it will perfect for my projects.
John N Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, I'd Buy It Again, High Quality, Reliable
Handy And Quiet
By Peter H
Florida
Review Posted 06/09/2022
Even though it is small, it recovers pressure quickly to 120psi. Great price!!
Peter H Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I'd Buy It Again, Easy To Store
Cons:
None
Perfect Compressor
By Justin O.
Cleveland, Ohio
Purchased 03/09/2022 |
Review Posted 03/25/2022
This compressor is very quiet. It runs at the same decibel level as a normal conversation. It is perfect for work environments that require minimal noise levels.
Justin O. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
5/5
Pros:
Quiet, Light Weight, Easy To Use, Id Buy It Again
Cons:
none
