Champion 37-Ton Horizontal/Vertical Gas Log Splitter

Model:

100250

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
View Champion 37-Ton Horizontal/Vertical Gas Log Splitter
Model:
100250
$1,999.99
Product Discontinued
Champion 37-Ton Horizontal/Vertical Gas Log Splitter
Champion 37-Ton Horizontal/Vertical Gas Log Splitter
Model: 100250
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

  • 338cc Champion 4-Cycle OHV Engine
  • Cast iron cylinder sleeve for durabilty
  • Low oil shutoff protects the engine
  • Allows For Horizontal & Vertical Splitting
  • Split smaller logs in the horizontal position
  • Switch to vertical & roll large logs into place- saves your back
  • Full steel beam design for maximum cylinder support
  • Handles logs up to 24" long
  • 2 Stage, 13 GPM Hydraulic Pump
  • 3600 PSI maximum from 5" x 23" cylinder
  • 16 second cycle time (225 cycles per hour)
  • Integrated Log Cradle
  • Keeps split logs on the beam; less bending over to stack
  • Log Strippers
  • Assist in removing log from wedge on the return stroke
  • 2-Inch Ball Hitch
  • 16-inch tires for smooth towing to your wood lot
  • Assembly Required
California residents see
Warning: This product can expose you to chemicals including Benzene which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

100250
specs product image PID-50955
Engine
Engine Brand
Champion
Starting System
Recoil Start
Engine Cycle
4-Cycle
CC
338 CCs
Fuel Tank Size
0.8 Gallons
Low Oil Shutdown
Yes
Hydraulics
Auto Return
Yes
Hydraulic Filter
Yes
Hydraulic Oil Included
No
Hydraulic Reservoir Size
5 Gallons
Max Pump PSI
3600 PSI
Cylinder Diameter
5 Inches
Cylinder Length
23 Inches
Cycle Time
16 Seconds
Tonnage
37 Tons
Overview
Assembly Required
Yes
Weight
566.6 Pounds
Made in USA
No
Consumer Warranty
2 Years
Product Length
92.4 Inches
Product Width
40.8 Inches
Product Height
46.1 Inches
Power Type
Gas
UPC
850878006372
Wedge
Wedge Material
Steel
Wedge Size
7 Inches
Wedge Style
2-way
Replaceable Wedge
Yes
Sharpenable Wedge
Yes
Log Capacity
Max Log Length
24 Inches
Towing
Towable
Yes
D.O.T. Lights
No
Fenders
No
Hitch Type
2 Inch Ball Hitch
Max Towing Speed
45 MPH
Accessories
Jack Stands
Included
Log Cradles
Included
Wood Type Hardness Rating 6" Seasoned 6" Green 12" Seasoned 12" Green 24" Seasoned 24" Green
Alder 590 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Ash 1320 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Aspen 420 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Basswood 410 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Beech 1300 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Birch 1470 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Boxelder 720 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Buckeye 350 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Catalpa 550 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Cedar 900 Lbs. 6+ Tons 8+ Tons 15+ Tons 20+ Tons 27+ Tons 30+ Tons
Cherry 950 Lbs. 6+ Tons 8+ Tons 15+ Tons 20+ Tons 27+ Tons 30+ Tons
Cottonwood 430 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Dogwood 2150 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Elm 1540 Lbs. 10+ Tons 13+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Fir 710 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Hickory 1820 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Locust 1700 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Magnolia 1020 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Maple 1450 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
Oak 1620 Lbs. 10+ Tons 13+ Tons 22+ Tons 27+ Tons 30+ Tons 35+ Tons
Pine 860 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Poplar 540 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Spruce 510 Lbs. 4+ Tons 6+ Tons 7+ Tons 9+ Tons 27+ Tons 30+ Tons
Sweet Gum 850 Lbs. 6+ Tons 8+ Tons 10+ Tons 13+ Tons 27+ Tons 30+ Tons
Walnut 1010 Lbs. 7+ Tons 9+ Tons 16+ Tons 22+ Tons 30+ Tons 35+ Tons
