Eemax AccuMix II™ 120 V / 3.5 kW Thermostatic Electric Tankless Point of Use Water Heater - Under Sink
Model:
AM004120T
+
Share This Product
Features
- Endless Hot Water
- Providing on demand hot water with no storage capacity to deplete, the Eemax AccuMix™ allows for endless hot water.
- Simple Installation
- Able to be mounted in any orientation using only NPT fittings that don't require soldering, as well as only one input line needed, the Eemax AccuMix™ is simple to install.
- Field Serviceable
- With all major components easily accessible and able to be replaced in the field, service is simple with the Eemax AccuMix™.
- SafeStart™
- With SafeStart™ technology, the Eemax AccuMix™ engages upon start-up to prevent dry-fire episodes.
- Self-Diagnostic
- The Eemax AccuMix™ with it's intelligent controls, actively protects the water heater.
- Applications
- Provides hot water for kitchen sinks, bars, utility sinks, single lavatory faucets and more.
Eemax is the #1 supplier of tankless water heater solutions in the USA. For over 25 years, Eemax has offered energy efficient, on demand hot water heaters for commercial applications, residential homes, industrial and safety applications. Eemax is a green, environmentally friendly company that offers the largest selection in the industry. Ideal for applications such as retail outlets, schools, office spaces, restaurants or any remote sink without hot water.
Product Note
Ideal installation orientation is vertical. The temperature of this heater has been Eemax factory set at 105° F for handwashing applications and must not be adjusted.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
AM004120T
Overview
Product Category
Water Heater - Point of Use
General Information
Type
Tankless Water Heater
Product Line
AccuMix II
Product Category
Water Heater - Point of Use
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Electric
Storage Type
Tankless
Application
Commercial/Industrial
Connection Type
Compression
Mount Type
Wall
Installation Location
Under Sink
Performance
Electric Heat Capacity
3.5 kW
Flow Rate at 40F Temperature Rise
Flow Rate at 40F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
0.6 GPM
Flow Rate at 45F Temperature Rise
Flow Rate at 45F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
0.5 GPM
Flow Rate at 50F Temperature Rise
Flow Rate at 50F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
0.5 GPM
Flow Rate at 60F Temperature Rise
Flow Rate at 60F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
0.4 GPM
Flow Rate at 70F Temperature Rise
Flow Rate at 70F Temperature Rise
Flow rate measures how much hot water your heater can deliver. Click Learn More to determine the appropriate temperature rise to use based on your location. Learn More
0.3 GPM
Minimum Output Pressure
35 PSI
Maximum Output Pressure
150 PSI
Uniform Energy Factor
Uniform Energy Factor
Uniform Energy Factor (UEF) is a measurement of water heater energy efficiency. The higher the energy factor, the more efficient the water heater.
0.93
Minimum Flow Rate
0.3 GPM
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Current Draw
29 Amps
Dimensions
Cold Water Inlet
3/8 Inch
Hot Water Outlet
3/8 Inch
Product Height
13 3/4 Inches
Product Width
4 Inches
Product Depth
5 1/4 Inches
Product Weight
6 Pounds
Certifications
UL Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
