Honeywell™ Commercial 400-Amp Automatic Transfer Switch (120/240V 3-Phase)

Model:

RTSZ400J3

Write A Review
$2,169.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 4-6 Weeks

Honeywell™ Commercial 400-Amp Automatic Transfer Switch (120/240V 3-Phase)
Honeywell™ Commercial 400-Amp Automatic Transfer Switch (120/240V 3-Phase)
Model: RTSZ400J3
$2,169.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Type

Standard

Amp Rating

400

Load Mgmt.

Not Compatible

Voltage

120/240 Three-Phase

Enclosure

NEMA 3R

  • 400-Amp Automatic Transfer Switch (120/240V 3-Phase)
  • For 120/240V 3-Phase Honeywell™ Commercial Generators
  • Aluminum, NEMA Type 3R Enclosure
  • Weather-resistant design for indoor & outdoor installation
  • Electrostatically applied and baked powder coating paint (Gray)
  • Designed For Standard Installation*
  • May require a sub-panel for overload protection
  • Work's With Honeywell's Sync 1.0™ Generator Controller
  • Generator's controller handles all the timing, sensing & exercising
  • Electrically Operated, Mechanically-Held Contacts
  • For fast, positive connections that you can depend on
  • Tech Spec Summary: (See Spec Sheet For More Info)
  • Rated 400-Amps @ 240V 3-Phase
  • Transition Type: Open
  • Withstand Rating: 25,000 Amps --- Lug Range: 400 MCM - #4
  • 2-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Di-n-butyl phthalate (DBP) which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

RTSZ400J3
specs product image PID-62393
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
133 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
36.1 Inches
Product Width
24 Inches
Product Height
10 Inches
UPC
696471612820
Product Specs
Voltage
120/240 Three-Phase
Frequency
60 Hertz
Rated Amps
400 Amps
Enclosure
NEMA 3R
Transfer Switch Style
Standard Installation
ATS Load Prioritizing
Not Compatible
ATS Load Shedding
Not Compatible
ATS Poles
3 Poles
ATS Service Disconnect
No
Max Utility Input
400 Amps
Max Generator Input
400 Amps
UL Listed
Yes
