Features
Style
Refrigerated
Dryer Voltage
115V 1-Phase
Air Dryer CFM
15
Rated HP
5
Ingersoll Rand Non-Cycling Refrigerated Air Dryer 5HP (15 CFM)
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- For Use With Compressors With Aftercoolers
- Keeps damp air from rusting tools & washing away lubricants
- ISO Class 6 Dryer Is Reliable And Operationally Efficient
- 15 CFM with exceptionally low pressure drop; 5 HP motor
- Integral stainless steel moisture separation
- Continuous Pressure Class H Dew Point Performance
- Optimized pressure 50°F dew point
- Temperature driven variable speed fan for continuous heat removal
- Electronic solenoid drain valve for optimal performance
- User Friendly Controls
- Simple, easy to read control panel uses a color coded diagram
- Environmentally Friendly
- Uses 115V, 1 phase, 2.23 amp power and R134A refrigerant
- Sturdy, powder coated finish
- Aluminum braze plate heat exchanger
- Professional Features
- Maximum pressure of 203PSI
- Maximum inlet temperature of 140°F; maximum ambient temp 122°F
- 3/8" NPT inlet & outlet fittings
- Installation of an upstream 1.0 micron prefilter is recommended
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
D25IN
General Information
Product Category
Air Compressor Accessories
Air Dryer
Dryer Voltage
115V 1-Phase
Air Dryer CFM
Air Dryer CFM
All compressed air dryers have a maximum drying capacity expressed in Cubic Feet Per Minute (CFM)
15
Max PSI
Max PSI
The most amount of PSI that be passed through a dryer
203
Max Inlet Temp. Rating
Max Inlet Temp. Rating
The highest temperature the compressed air can be passing through the dryer for the dryer to operate properly and effectively
140
Max Ambient Temp. Rating
Max Ambient Temp. Rating
Ambient temperature is the air temperature of any object or environment where equipment is stored
122
Non-Cycling
Non-Cycling
Non-cycling refrigerated air dryers have refrigeration compressors that start as soon as you turn the dryer on ― and don't stop until you turn the dryer off. They are less expensive than cycling dryers and are a good choice for applications where they will constantly run at full capacity
Yes
Inlet Fittings
3/8"
Outlet Fittings
3/8"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
Yes
Auto Drain
Auto Drain
Auto drain or drip leg drain used to drain air line of condensate and water
Yes
Regenerative
No
High Temp
High Temp
Dryers that are specifically designed to handle higher inlet temperatures than regular dryers. Typically paired with a piston or reciprocating air compressor
No
Rated HP
Rated HP
Possible corresponding compressor HP
5
Overview
Product Category
Air Compressor Accessories
Weight
40 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
16 Inches
Product Width
12 Inches
Product Height
16 Inches
Power Type
Electric
UPC
678384318143
Reviews
(6)
Ingersoll Rand D25IN Reviews & Ratings
Perfect
By Cristobal A.
Virginia
Purchased 06/21/2024 |
Review Posted 07/12/2024
It was just the right size, perfect for our compressor.
Cristobal A. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Cons:
None
Ingersol Rand D25IN
By Yvonne R.
Statesboro, Georgia
Purchased 02/21/2018 |
Review Posted 03/16/2018
Our shop finally replaced our old Zeks dryer with the Ingersol Rand D25IN dryer after many attempts to patch up the Zeks. The IR D25IN is considerably smaller which allows for more shop space. It is very quiet and cycles out the chilled air a lot more times than the other dryer. We are all around very pleased with our purchase and would recommend the IR D25IN to any other facility which requires dry air for use. Thanks Ingersol Rand. D. Craig R. @ Craig's Collision Center Inc. Statesboro, Ga. 30458
Yvonne R. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Price, Reliable
Very versatile
By Sean W.
Denver, Colorado
Purchased 05/28/2015 |
Review Posted 10/22/2015
Even with the large amount of air we use, this unit stay low on its dew point levels. Every option is adjustable and versatile. Good purchase.
Sean W. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
IR Air Dryer
By Pat Spence
Cleveland, Texas
Purchased 08/15/2014 |
Review Posted 09/07/2014
We were experiencing cutting issues on our Plasma Table due to the high humidity we have in the area.
Pat Spence Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Reliable, I'd Buy It Again
Good service, great machines
By Roger S.
Cambridge, Minnesota
Purchased 09/12/2012 |
Review Posted 10/03/2012
I have bought 2 compressors and 1 dryer in the last 3 months- Good service, great machines.
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Air Dryer
By Dave M.
Delhi, Iowa
Purchased 07/03/2012 |
Review Posted 08/14/2012
I used it for about 30 min and fault light came on and it's not fixed yet. Right now, not happy with it.
Was this review helpful?
Expert Response
This unit has a 1 year Factory Warranty through Ingersoll Rand. You can give them a call directly, toll free, at (800) 866-5457, or click on the Service Centers link at the bottom of our web site to find the Authorized Warranty Service locations near your zip code.
Dale V.
Power Equipment Expert
Rating Breakdown
1/5
1/5
1/5
1/5
Product Q&A
(1)
Product Questions
Answered by Melissa, the Air Compressor Expert
i have speedaire 80 gal 7.5 hp air compressor to use for automobile paint.
i am getting water out from line now days, and i like to dry out so no water going to come out when i spray.
is this product(ir d25in)can do this job and good size for compressor i have????
Brian Yoo
from Virginia
