Pro Series S3100-DFC2 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch

Model:

S3100-DFC2

Write A Review
$606.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Friday, Nov 22nd
Shipping to60601

Pro Series S3100-DFC2 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch
Pro Series S3100-DFC2 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch
Model: S3100-DFC2
$606.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Primary

GPH

5940 Gallons

Switch Type

Dual Vertical Sensor

  • Cast Iron / Stainless Steel Construction
  • Energy Efficient Permanent Split Capacitor (PSC) Motor
  • Piggy-back Dual Float Switch with Cage
  • Deluxe Controller
  • Monitors power conditions and sounds an alarm when:
  • AC power is out or circuit breaker is tripped
  • Float has been raised for more than 10 minutes
  • 9-volt battery needs replacement
  • Continuous Duty Rated
  • Stainless Steel Shaft
  • Dual Carbon/Ceramic Seals
  • 20' Pump Cord
  • Output terminals for Connection to a Security System or Auto-dial
  • Water Cooled (no oil)
  • 3-year warranty (1 year for continuous duty)

Specifications

S3100-DFC2
specs product image PID-6572
General Information
Product Category
Sump Pump
Base
Base Material
Cast Iron
Motor
Voltage
120 Volt
Running Amps
11.5
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
Yes
Nominal Voltage
120 Volt
Starting Amps
18
Pump
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
.25 inch
Handles Solids
Yes
Total Head Lift
52 Feet
Float Type
Dual Vertical Sensor
GPH @ 0 feet
5940
GPH @ 10 feet
5520
Discharge Port Size
2 Inch
Float Cord
10 Feet
Check Valve Included
No
Manual Override
Yes
Engine
Horsepower
1 HP
Overview
Product Category
Sump Pump
Weight
46 Pounds
Consumer Warranty
3 Years
Commercial Warranty
1 Year
Product Length
11 Inches
Product Width
7.7 Inches
Product Height
18 Inches
UPC
717301121678
Additional Model Numbers

S3100, S3100-DFC2

Reviews

(8)
Pro Series S3100-DFC2 Reviews & Ratings

Product Q&A

(4)
Expert avatar photo
Product Questions Answered by Jim, the Sump Pump Expert
what is the difference between a sewer injector pump and a sump pump? can i use the same pump for each activity? thanks
Russell Abrams
from New York
October 29, 2012
Can you set the on depth and off depth on the dual sensor switch, like on at 1/2 ft and off at 3"?
Don F
from Minnesota
July 15, 2012
for my cabin i need a sump pump that will have a lift of 40 ft and less than 10 gaper minute. the distance is 42 feet. what size of discharge pipe will be needed and also a check valve thank you
Dave Higgins
from Washington
August 06, 2011
What is a dual vertical sensor switch?
Mitch Miller
from Montana
June 11, 2011
