Reliance Controls CSR202
Reliance Controls CSR202
Hover to zoom
1 of 1

Reliance Controls 20-Amp (240V 1-Circuit) Outdoor Transfer Switch

Model:

CSR202

Write A Review
$212.99
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Reliance Controls 20-Amp (240V 1-Circuit) Outdoor Transfer Switch
Reliance Controls 20-Amp (240V 1-Circuit) Outdoor Transfer Switch
Model: CSR202
$212.99
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Optional Accessories 4
$76.50
Only 4 In-Stock
$54.99
Factory-Direct
$40.99
Only 1 In-Stock

Features

Type

Manual

Amp Rating

20

Circuits

1

Voltage

120/240 Single-Phase

Enclosure

NEMA 3R

  • Outdoor Installation
  • Ideal for well pumps, traffic signals, cell towers, etc.
  • Raintight Connection
  • Accomodates cord even when cover is closed and latched
  • Double-Throw Switch
  • Isolates the generator from the utility line at all times
  • UL Listed
  • Certified for use by Underwriter Laboratories
  • MAX. COMBINED LOAD @ 125 VAC - 40A - 2 Circuits
  • MAX. COMBINED LOAD @ 250 VAC - 20A - 1 Circuits
California residents see
Warning: This product can expose you to chemicals including Cadmium which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA L14-20R
CSR202
specs product image PID-1103
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
10 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Product Length
8.75 Inches
Product Width
7.5 Inches
Product Height
6.25 Inches
UPC
851890000331
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
5000 Watts
Rated Amps
20 Amps
Enclosure
NEMA 3R
Number of Circuit Breakers
1
Max Generator Input
20 Amps
Maximum Wattage
5000 Watts
UL Listed
Yes
Transfer Switch Circuits
20A 240V
1
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-20R
1
