Transair 1-Inch (25mm) Quick Assembly Mini Bracket w/ 1/2-Inch Female NPT Thread (Box of 10)
Model:
6663 25 22
+
Share This Product
Recommended Accessories
![Power Equipment Direct expert image](http://www.powerequipmentdirect.com/images/experts/expert-avatar-1.png?v=1)
Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Transair Fast, Flexible & Easy-To-Use Series Pipe Connectors
- Most effective and efficient compressed air piping system
- Offers significant savings on installation and maintenance
- Helps overcome constraints in structures of industrial buildings
- Lightweight Quick Assembly Mini Bracket
- Integral water retention device & high flow rate
- Offers quick installation without having to cut any pipes
- For vertical or horizontal take-offs using either rigid pipe or flexible hose
- Non-Corrosive Polyamide Material
- 100% recyclable, silicone-free and made of non-flammable materials
- Resistant to minerals, synthetic compressor oils & aggressive environments
- Full Bore Design
- Delivers high flow with extremely low-pressure loss
- Ideal for automotive assembly, industrial and food & beverage
- Quick Connection Technology
- Eliminates special install tools and the need to solder pipe
- Allows systems to be modified and reconfigured in minutes
- 1" Outer Pipe Diameter; 1/2" Female NPT
- Max working pressure 232; Max working temp 140 F
- 188psi when system is operated between -4 to 140 F
- 232psi when system is operated between -4 to 115 F
- Transair 10-Year Guarantee
- Leak free, easy-to handle and safe to work with on elevated platforms
- Suitable for compressed air (dry, wet, lubricated) and inert gases
California residents see
Warning: This product can expose you to chemicals including Lead and lead compounds which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
6663 25 22
![specs product image PID-96824](/products-image/150/mass_96824_1000.png)
General Information
Product Category
Air Compressor Accessories
Air Tools
Max Tool PSI
232
NPT
1/2"
Size
1"
Overview
Product Category
Air Compressor Accessories
Weight
0.45 Pounds
Consumer Warranty
10 Years
Commercial Warranty
10 Years
Product Length
5.75 Inches
Product Width
8 Inches
Product Height
6 Inches
